3D Frozen Meat Dicer (400-900kg/h) Manufacturer

3D Frozen Meat Dicer (400-900kg/h)

Request a Quote

View All: http://foodmachine-en.com/1-1-9-3d-frozen-meat-dicer.html

Meat Processing Equipment

Industrial meat cutting machine for cutting frozen boneless meat, poultry and fish into cubes

Cutting Size Customizable

Processing Capacity 400-900 kilograms per hour

Our 3D frozen meat dicers are designed for cutting of frozen boneless meat, poultry, and fish into uniform cubes with precision. Using a three-knife system, the meat dicing machine performs three successive cuts to achieve consistent cube sizes. By adjusting the number of blades in the grid, the 3D meat cutter can produce meat cubes of different dimensions, offering versatility for various processing needs.

Applications

This dicer is perfect for processing frozen boneless meat, poultry, fish, and seafood into cubes, making it an excellent choice for food processing facilities and central kitchens focused on consistent and efficient operations.

3D Frozen Meat Dicer, DRB-R350H

Model: DRB-R350H
Voltage: 380V, 50Hz
Power: 3.2kW
Processing capacity: 400-600kg/h
Cutting size: customizable
Feed chamber size (L×W×H): 390×84×84mm
Raw material temperature: -4 to 0℃
Dimensions (L×W×H): 1415×775×985mm
Weight: 332kg

3D Frozen Meat Dicer, DRB-R550H

Model: DRB-R550H
Voltage: 380V, 50Hz
Power: 3.7kW
Processing capacity: 600-900kg/h
Cutting size: customizable
Feed chamber size (L×W×H): 550×120×120mm
Raw material temperature: -4 to 0℃
Dimensions (L×W×H): 1740×995×1105mm
Weight: 489kg

Features

Prioritizes safety by stopping the rotating knife immediately when the front door is opened, ensuring operator protection.
Cleaning and maintenance are easy, as the cutting grid and large blades can be fully disassembled without using additional tools.
Its fork structure enhances cutting quality, reduces noise, and minimizes the likelihood of mechanical failures.
Precision cutting is achieved with an optional PLC and touchscreen system, allowing convenient adjustments to blade thickness.
Made from thick 304 stainless steel, our meat dicer is built to meet food hygiene standards and endure thorough cleaning processes.
