Class 100 oven/Clean Room Oven
Request a Quote
This dustless industrial drying oven has a most prominent characteristic of maintaining cleanliness at a high level, that means a dust particle of 0.5μm has to be controlled less than 100 per square meter. A dustless industrial drying oven is mainly used for products requiring high level of cleanliness, such as cellphone, digital camera, LCD touch screen, etc.The common drying temperature range of dustless industrial drying oven is ambient temperature to 200℃. Dustless industrial drying ovens with the highest drying temperature of 300~600℃ need to be customized.Features
The inner chamber adopts an 8K mirror surface stainless steel plate. Thanks to this, the dust cannot be attached to the inner chamber. Then through internal hot air circulation, the dust will be filtered by the high-efficiency air filter when reaching the air duct. During the drying process, the inner chamber needs to be sealed tightly and entirely, so that no dust will be produced. And the internal pressure of the inner box should be a little higher than external pressure to prevent the dust entering the inner chamber.According to the dimensions of the oven, we can offer clients a series of dustless industrial drying ovens with different specifications. The basic parameters are listed below.
The inner chamber adopts an 8K mirror surface stainless steel plate. Thanks to this, the dust cannot be attached to the inner chamber. Then through internal hot air circulation, the dust will be filtered by the high-efficiency air filter when reaching the air duct. During the drying process, the inner chamber needs to be sealed tightly and entirely, so that no dust will be produced. And the internal pressure of the inner box should be a little higher than external pressure to prevent the dust entering the inner chamber.According to the dimensions of the oven, we can offer clients a series of dustless industrial drying ovens with different specifications. The basic parameters are listed below.
| Model | MOL-2DF |
| Internal Dimension (W×D×H) (mm) | 600×600 × 1000 (Inner box) |
| External Dimension (W×D×H) (mm) | 1500×860×1760 |
| Power (kVA) | 7kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±1% |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ5 Automatic |
| Model | MOL-8WS |
| Internal Dimension (W×D×H) (mm) | 840×710×153 （single box） |
| External Dimension (W×D×H) (mm) | 3160×1215×2455 |
| Power (kVA) | 24kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±2% |
| Air inflow | N2 or Clean Air, Max: 100L/min |
| Filtration efficiency | 99.99% |
| Cleanliness class | Class100 |
| Air Outlet | Φ5 Automatic |
| Model | MOL-1F |
| Internal Dimension (W×D×H) (mm) | 300×400×40 |
| External Dimension (W×D×H) (mm) | 560×840×980 |
| Power (kVA) | 3kVA |
| Temperature Range | Room Temperature~200℃ |
| Temperature uniformity | ±1℃ |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ3 Automatic |
| Model | MOL-1ND |
| Internal Dimension (W×D×H) (mm) | 450×400× 400 |
| External Dimension (W×D×H) (mm) | 710×840×980 |
| Power (kVA) | 3kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±1℃ |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ3 Automatic |
| Model | MOL-2ND |
| Internal Dimension (W×D×H) (mm) | 600×500×600 |
| External Dimension (W×D×H) (mm) | 860×940×1280 |
| Power (kVA) | 5kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±1% |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ3 Automatic |
| Model | MOL-3ND |
| Internal Dimension (W×D×H) (mm) | 600×500×900 |
| External Dimension (W×D×H) (mm) | 860×1150×1780 |
| Power (kVA) | 6kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±1% |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ5 Automatic |
| Model | MOL-4ND |
| Internal Dimension (W×D×H) (mm) | 800×600×1000 |
| External Dimension (W×D×H) (mm) | 1060×1250×1880 |
| Power (kVA) | 7kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±1% |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ5 Automatic |
| Model | MOL-7F |
| Internal Dimension (W×D×H) (mm) | 1200×700×1300 |
| External Dimension (W×D×H) (mm) | 1960×1015×2140 |
| Power (kVA) | 20kVA |
| Temperature Range | Room Temperature ~200℃ |
| Temperature uniformity | ±2% |
| Air Inflow | N2 or Clean Air, Max: 100L/min |
| Filtration Efficiency | 99.99% |
| Cleanliness Class | Class100 |
| Air Outlet | Φ5 Automatic |
Six point temperature meter, printing machine, temperature logging device, touch screen, USB and computer monitoring system, multi-step programmable controller, RS485 interface and communication software, wireless alarm system, USB flash drive.
Features
1. Dustless and highly uniform temperature distribution
2. The cleanliness class is class 100
3. Automatic air exchange, automatic cooling
