Label Offset Printing Machine (PS Plate)

Label Offset Printing Machine (PS Plate)
Request a Quote

The advanced servo control system of the label PS offset printing machine ensures the stable movement of printing stock during the printing process. The printing cylinders do not need changing and repeat length is digitally controlled. The label PS offset printing machine is quick, easy and convenient to operate. The only operation is inputting the preset printing length on the main control panel, and then every printing unit will be automatically positioned.

Printing Section

The label PS offset printing machine is a heavily constructed offset printing unit. It consists of 19 ink rollers (including 4 ink form rollers and a total of 4 dampening rollers). The long ink roller train efficiently eliminates streaking and ghosting in the image. The dot sharpness and register are exceptional.

Shaftless Drive System

Each printing unit is driven by an independent servo motor; 14 sets of servo motors in total for a 6 color machine ensures overprinting precision at high speed.

Color Registering System

The vertical and horizontal position of every printing form is controlled by independent motor, which reduces labor and material waste. The label PS offset printing machine can change vertical and horizontal registering without stopping.

Extremely Large Printing Area

High-precision photocells ensure multi-register print on both sides. 300×350mm (W×L)

Declutching

Every printing unit is equipped with a clutch device, so each unit can be stopped independently when not needed. This system extends the machine's servicing life and saves roller wear.

Various Options

UV varnishing unit, rotary and flat-bed die-cutting units, hot stamping and Spot UV units are available. Magnetic rotary die-cutting cylinders are used for changing different flexible die plates for in-line printing and die cutting.

Fingertip Control

The label PS offset printing machine has a touch screen, faster CPU, 12 inch LCD display area, facilitates parameter setting and offers trouble shooting.
It is a PS or CTP plate intermittent offset press suitable for high grade label printing in low, medium or long run production. Its main features are speed of setup, international components and affordability.

Technical Specifications of the Label Offset Printing Machine (PS Plate)
Model SBD320Z
Printing speed 50-180 ipm
Printing color 2 3 4 5 6
Max. printing length 350mm
Max. web width 320mm
Max. printing width 300mm
Max. unwinding diameter 600mm
Max. rewinding diameter 600mm
Electricity 380V, 50HZ, 3PH
Total power 33.6Kw
Machine weight 9500kg
Machine dimension 8850×1600×1850mm

We are a specialized label PS offset printing machine manufacturer based in China. We offer various types of products such as die cutting flexo printing machine, rotary head film blowing machine, hot foil stamping and die cutting machine.

At CBADEN, we supply an extensive range of converting & printing machines and provide comprehensive services to accommodate customer's individual production demands.
