Label Slitter
Request a Quote
Slitting machine for narrow labels
Model SAK320/450/600
The label slitting machine is the one associated with die-cutting machinery, used for small size reel material slitting. It has the function of automatic meter counting, automatic stopping, web guiding by photoelectric eye.
Features
- The label slitting machine is a compact structure with fast speed, high efficiency, easy operation, accurate slitting, steady running, etc.
- It uses a rewinding and unwinding shaft and the tension is controlled by friction paper (magnetic powder clutch and brake are optional); the unwinding unit has the function of auto web-guiding, and the photoelectric eye is KONTEC brand (Taiwan).
- The label slitting machine has auto meter and label counter (SICK brand, Germany), which can set the length and amount. The machine can stop automatically.
Technical Specifications of the Label Slitting Machine
Model | SAK320/450/600 |
Working speed | 75m/min |
Max. width of material | 320/420/570mm |
Max. diameter of unwinding | 500mm |
Max. diameter of rewinding | 480mm |
Precision | ±0.5mm |
Machine weight | 400-680kg |
Machine dimension | 1100×900-1100×1280mm |
As a professional label slitting machine manufacturer and supplier based in China, we also provide label and paper rotary die cutting and slitting machine, plastic bag making machine, die cutting creasing machine, and much more.
At CBADEN, we supply an extensive range of converting & printing machines and provide comprehensive services to accommodate customer's individual production demands.
