Xuzheng hydraulic 2-roll plate bending machines are designed for rolling and bending thin plates with thickness less than 4mm, to meet the needs of pre-processing of sheet metal from tank manufacturers, cylinder manufacturers, tube manufacturers.

These plate bending rolls are widely used for processing water heater tank, air tank, fire extinguisher, air compressor tank, resonator pipe, air duct in various industries, including auto parts, solar water heaters, food machinery, metal processing equipment, etc.

The maximum thickness of materials processed by this hydraulic plate rolling machine reaches 6mm, and diameter less than 600mm. By adopting high grade polyurethane rollers, it can ensure stable operation and long service life.

  • Applicable materials:
      Carbon Steel, Stainless Steel, Aluminum, Copper, etc;
Specifications
Standard Type
ITEM XZJYJ-500 XZJYJ-700 XZJYJ-1000 XZJYJ-1500
Rated Power(KW) 3 3 6 6
Hydraulic Pressure Range(Mpa) 3~8 3~8 4~12 4~12
Work-piece Thickness(mm) 0.8~2.5 0.8~2.5 0.8~3.5 0.8~3.5
Work-piece Diameter(mm) 90~300 100~300 150~450 200~450
Work-piece Length(mm) 50~500 50~700 50~1000 50~1500
Dimension (L*W*H) (mm) 1900*1000*1200 2300*1000*1300 2900*1000*1400 3300*1000*2100
Weight(Kg) 1100 1500 1800 2400
Custom Type
ITEM XZJYJ-Z-500 XZJYJ-Z-700 XZJYJ-Z-1000 XZJYJ-Z-1500
Rated Power(KW) 6 6 7.7 7.7
Hydraulic Pressure Range(Mpa) 4~12 4~12 5~16 5~16
Work-piece Thickness(mm) 0.8~6 0.8~6 0.8~6 0.8~4
Work-piece Diameter(mm) 100~450 100~450 200~600 200~600
Work-piece Length(mm) 100~500 100~700 100~1000 100~1500
Dimension (L*W*H) (mm) 2500*1000*1400 2500*1000*1400 3100*1100*1500 3500*1100*1500
Weight(Kg) 1800 1800 2300 2700
