LQ-MD-AD 350/580

Digital finishing press for creating 3D effects on various substrates

The digital 3D varnishing and stamping machine is designed to enhance printed materials with brilliant foil effects, suitable for offset, flexo, and digital press outputs. This innovative machine allows for the application of foil on a diverse range of surfaces including coated and uncoated papers, synthetic plastics, laminated films, and aqueous coated surfaces. With its precise camera registration, the varnishing and coating machine is capable of creating digital and variable embellishments such as ultra-fine lines, intricate small lettering, and detailed texture effects. Ideal for both quick prototyping and efficient high-volume production, this coating and foiling equipment is a is suitable to enhance the visual appeal and tactile quality of printed materials. Its capability to process complex designs with high precision makes it an essential asset for industries looking to produce eye-catching marketing materials, luxury packaging, and bespoke printed products.

Applications
Specifications
Model AD580 AD350
Coating Means DOD inkjet heads
Embellishment Spot UV, texture, 3D foil, sandy effect
Resolution 1080dpi, 720DP1, 360dpi
File Format TIFF, PDF, PS
Sheet Size 580×760mm 297×210inm 350×645mm 297×210mm
Max.Working Size 570×750mm 350×645mm
Max.Working Speed 3000sheets/hour (720 dpi) 3600sheets/hour (720 dpi)
Registration Accuracy ±0.15mm
Max. Foil Length 500m
Max. Loading Height 550mm
Total Power 12kW 380V SOHZ
Weight 2000kg 1800kg
Dimensions 6500×l600×l850mm
Features
  • The varnishing and stamping machine is equipped with an inkjet control system that processes complex designs swiftly and effectively. This efficient handling improves operations, enhancing productivity without the need for complex settings
  • Comes with a basic setup that can be extended to meet diverse production needs, enhancing its adaptability for various projects
  • Capable of working with an extensive array of materials, from various papers to synthetic plastics and films, this machine offers versatility in handling diverse printing tasks
  • Engineered to work at varying speeds and with different material thicknesses, the coating and foiling machine provides flexibility to match the pace and scale of your production requirements
  • Equipped with a function for fine line creation and detailed patterns through Spot UV and foiling, this feature enhances the aesthetic appeal of prints with precision
  • Thanks to its advanced printing heads and UV varnish, the coating and stamping machine maintains stable performance and delivers high-quality, consistent embellishments
  • With an advanced PLC-based negative pressure and ink supply system, this UV coating and foiling machine offers automated control over ink flow and pressure, ensuring precise and hassle-free print quality.
