Inkjet Rotary Digital Printing Machine
Double-sided digital printer
The inkjet rotary digital printing machine is built to meet the diverse needs of modern printing businesses. This printing machine is available in models with paper widths of 440mm and 560mm, making it versatile enough to handle various printing sizes, from small custom jobs to large commercial runs. It supports both roll-to-sheet and roll-to-roll processes, allowing businesses to enhance their operations based on specific production requirements. Our digital printer is known for its high-quality printing output and stable performance, ensuring that every printing job is completed efficiently and cost-effectively. It's an excellent investment for businesses focused on on-demand printing and larger commercial printing tasks because it combines low operating costs with high productivity, leading to greater profitability.
- Drawing books
- Magazines
- Menus
- Short edition books
- Invitation cards
- Leaflets
| Model | UJET Creative Series | ||
| Pre-Press Workflow | Flow Path | Intelligent digital workflow, automatic template, one click processing | |
| Make-Up | Glue binding, saddle stitch binding, hardcover and custom assembly methods | ||
| Rip | Multi threaded high-speed RIP, text edge optimization | ||
| File Format | PDF, TIF, JPG, postscript and variable data, etc | ||
| Inkjet System | Printing | 4-color double-sided | |
| Printing Technology | Multiple grayscale levels | ||
| Print Head Type | Industrial grade on-demand piezoelectric nozzle | ||
| Print Speed | 70m/min | ||
| Print Width | 434mm/532mm/660mm | ||
| Resolution Ratio | 600×600dpi (normal)600×1200dpi(Max) | ||
| Printing Platform | Paper Width | 440mm/560mm/680mm | |
| Reel Diameter | Max.1270mm | ||
| Curl Flattening | Standard | ||
| Automatic Deviation Correction | Standard | ||
| Electrostatic Precipitator | Standard | ||
| Dry System | Automatic hot air IR | ||
| Cutting Sizes | 130~580mm(Option Max.700mm) | Rolling | |
| Stack Height | 230mm | ||
| Paper And Ink | Paper | Digital printing paper, regular double adhesive paper | |
| Paper Weight | 45-165gsm | ||
| Ink | eQD water-based ink | ||
| Installation Requirements | |||
| Power Supply | 380V AC 80kW | ||
| Air Supply | 0.6~0.8Mpa | ||
| Humidity | 40~60%RH | ||
| Temperature | 20~25℃ | ||
- This inkjet rotary digital printing machine simplifies the printing process by allowing you to create and use templates for jobs with similar sizes. With just one click, you can import and print, making repetitive tasks faster and reducing manual effort
- Thanks to its design based on browser/server architecture, this rotary printer allows multiple users work together online and send jobs to different printers in the network. This feature makes it easier for teams to collaborate and increases the efficiency of your printing operations
- Equipped with quick setup options for templates and can handle multiple tasks at once, speeding up the overall workflow. It works with various file formats, including PDF and Tiff, as well as special Postscript files, to accommodate all types of printing needs
- With its built-in color management system, the inkjet rotary printer keeps colors accurate and consistent across all prints. This system helps maintain the quality of your printed materials by ensuring that colors look just as you expect them to
- The printer is great for jobs that need customized data on each piece, like personalized marketing materials or custom labels. It can even handle printing variable data while continuing other jobs, making your workflow smoother and more productive.
