LQ-MD 940

A digital printer suitable for printing on a variety of paper types

Our digital rotary printing machine is designed to achieve printing speeds of up to 165m/min while delivering consistent results on traditional paper. Using proprietary technology, the system provides high-speed halftone printing, anti-aliasing for smoother text, and edge sharpening for clear, precise linework.

The high-speed printing platform accommodates a wide range of traditional paper types, including 38-120gsm paper in widths from 440mm to 940mm. It is suitable for various materials such as offset paper, lightweight paper, newsprint, rice paper, and carbonless copy paper. The circulating hot air drying system ensures accurate temperature control with internal and external air circulation and heat energy recycling, enabling efficient paper drying with minimal power consumption.

This digital rotary printing machine is ideal for meeting the diverse needs of modern printing operations.

Specifications
Max. Paper Width 940mm
Max. Print Width 890mm
Max. Printing Speed 165m/min
Max. Winding Diameter 1200mm
Gram Weight of Paper 1200mm
Printing Resolution Equivalent to offset printing 175-200 lpi
Rated Power 43kW/51kW/67kW (monochrome/two-color/four-color)
Air Source Requirement 0.6-0.8MPa
Dimensions 12×4.5×2.6m
Working Environment Temperature: 20℃ to 24℃ Humidity: 45-65% (no condensation)
