Spouted pouch, also known as fitment pouch is an extension of stand-up pouches which are becoming more prevalent for flexible packaging needs. Spouted stand-up pouches are commonly structured with different laminates to meet various food packaging application needs. These flexible pouches contain liquid products safely and make it easy to drink and pour while the tight seal is created to prevent leaks. Increasingly popular with on-the-go consumers, spouted pouches are an ideal choice of drink pouches for powder and beverage manufacturers.

Features

Coupled with high-precision molded spout, high barrier materials are adopted to prevent products from premature expiration and oxidation;
Recloseable spout keeps liquids and powders sealed tightly, easy to carry;
The design of threaded cap provides better sealing performance;
These spouted pouches can be filled with hot liquids, and can be refrigerated;
Multilayer laminated structure offers high strength and strong carrying capacity, while remaining leakage free;
Rounded corners are a user-friendly design, safe to use;
These pouches are printed utilizing professional printing machines, giving superior look and feel;
Can be used as retort pouch suitable for ready foods like sauces and meals that need to be pasteurised or sterilized at high temperature up to 121°C;

Customization

A wide range of options for spouts & fitments are offered, with diameter ranging between 8.2mm and 8.6mm;
Various logo and image can be printed per customer’s specific needs;

Material

PET/VMPET/PE
PET/NY/PE
PET/AL/NY/PE
PET/NY/RCPP
PET/AL/NY/RCPP

Options of Specifications

Shown below are some of pouches we ever made before. They can be custom printed with your designs, patterns, logos, etc.

Capacity: 5L
Material: PET12/PA15/White PE200
Dimensions: 320mm*350mm 80mm
Spout diameter: 15mm

Capacity: 3.465L
Material: PET/AL7/NY15/PE150
Dimensions: 280mm*350mm 60mm
Spout diameter: 15mm

Capacity: 4000ML
Front panel material: PET/NY15/PE170
Back panel material: PET12 VMPET12 PE170
Dimensions: 300mm*317mm 65mm
Spout diameter: 20mm

Capacity: 2L
Material: PET12/NY15/PE100
Dimensions: 190mm*275mm 50mm
Spout diameter: 33mm

Capacity: 1L
Material: PET12/AL07/NY15/PE116
Dimensions: 155mm*280mm 40mm
Spout diameter: 10mm

Capacity: 710ML
Material: PET12/NY15/PE160
Dimensions: 241mm*159mm 43mm
Spout diameter: 33mm

Capacity: 250ML
Material: PET12/VMPET12/PE90
Dimensions: 100mm*220mm 30mm
Spout diameter: 8.6mm

Capacity: 500ML
Material: PET12/AL07/NY15/PE120
Dimensions: 140mm*220mm 40mm
Spout diameter: 8.6mm

Capacity: 1L&500ML
Material: PET12/AL7/NY15/LLDPE140
1LDimensions: 160mm*250mm 45mm
500MLDimensions: 125mm*215mm 35mm
Spout diameter: 15mm

Capacity: 200ML
Material: PET12/AL7/PET12/PE90
Dimensions: 190mm*100mm*30mm
Spout diameter: 8.6mm

Capacity: 1KG
Material: PET12/AL07/NY15/PE45
Dimensions: 169mm*249mm 50mm
Spout diameter: 10mm

Capacity: 250g
Material: PET12/VMPET12/PE85
Dimensions: 155mm*205mm 40mm
Spout diameter: 15mm

Capacity: 250&500ML
Material: PET12/AL07/NY15/LLDPE130
Dimensions: 115mm*175mm 30mm
Spout diameter: 15mm

Capacity: 250&500ML
Material: PET12/AL07/NY15/LLDPE130
250MLDimensions: 115mm*175mm 30mm
500MLDimensions: 140mm*230mm 40mm
Spout diameter: 10mm

Capacity: 150ML
Material: PET12/VMPET12/PE90
Dimensions: 120mm*125mm 20mm
Spout diameter: 8.6mm

Capacity: 237ML
Material: PET12/AL07/NY15/PE100
Dimensions: 173mm*105mm 30mm*2
Spout diameter: 9.6mm

Capacity: 150g
Material: PET12/VMPET12/PE85
Dimensions: 70mm*205mm 20mm
Spout diameter: 8.6mm

Capacity: 250ML
Material: PET12/ALU7/NY15/PE90
Dimensions: 80mm 55mm*160cm
Spout diameter: 8.6mm

Capacity: 250ML
Material: PET12/AL7/PET12/PE90
Dimensions: 105mm*188mm 35mm
Spout diameter: 8.6mm

Capacity: 150ML
Material: PET12/NY15/PE90
Dimensions: 125mm*125mm 25mm
Spout diameter: 8.6mm

Capacity: 245ML
Material: PET12/NY15/PE90
Dimensions: 74mm*170mm 22mm
Spout diameter: 8.6mm

Capacity: 90G
Material: PET12/AL07/NY15/PE90
Dimensions: 130mm*84mm 25mm
Spout diameter: 8.6mm

Capacity: 90G&113G
Material: PET12/AL07/NY15/PE90
90GDimensions: 130mm*84mm 25mm
113GDimensions: 139mm*84mm 25mm
Spout diameter: 8.6mm

Capacity: 15ml
Material: PET12/WHITE PE58
Dimensions: 45mm*120mm
Spout diameter: 8.2mm
