TBTBH-CJ60 Automatic Mixture Blender

TBTBH-CJ60 automatic mixture blender adopts advanced microprocessor controlling technology to present the blending temperature ranging from ambient temperature to 200℃. This automatic mixture blender can automatically control PID parameters and blending time, which is suitable to be used in the laboratory for the sample test.

Technical Parameters
Blending volume 60L
Temperature control range Room temperature~200℃
Temperature control accuracy ±5℃
Timing range 0~999s
Timing accuracy ±0.1s
Rotation rate of paddle Rotation speed: 67 r/min Revolution speed: 42 r/min
Blending motor 380V, 50Hz, 2200W, 1400r/min
Lifting motor 380V, 50Hz, 750W, 1400 r/min
Overall dimension 1066mm*650mm*2100mm
Net weight 1100kg
Power supply AC (380±10%)V, 50Hz, 30A (three-phase four-wire system, with zero line)
Ambient temperature -5℃~ 50℃
Relative humidity ≤80%
Standard accessories
No. Name Unit Qty
1 TBTBH-F60 Automatic Mixture Blender Set 1
2 Material sample heater Set 1
3 Climbing Table Piece 1
4 Dumper Set 1
5 Discharging groove Piece 2
6 Unloading groove Piece 1
7 Discharge shovel Piece 1
8 Crank Piece 1
9 Quantitative measuring cup (2L, 4L) Piece Each 1
10 Operation manual Piece 1
11 Quality certificate Piece 1
12 Repair guarantee Piece 1
