MDZE Series Magnetic Drive Pumps
Request a Quote
The series of magnetic drive pumps are applied for the transferring of a wide range of liquid types. The pumps adopt a unique design in which the flow passage are statically sealed inside to prevent the liquids from leaking and polluting the surrounding environment. Axial thrust balancing allows the pumps to operate stably and quietly. They are widely used in chemical engineering operations and are suitable for the handling of inflammable, potentially toxic, volatile, highly corrosive, easily condensed liquids, as well as liquids with a viscosity below 365 centistokes, or liquids with low amounts of non-ferrous particles.
Technical Parameters
- Shaft seal type: magnetic drive
- Casing & impeller materials: 304, 306L stainless steel
- Distance sleeve materials: 304L, 316L stainless steel, C276
- Max rated pressure at 20℃: PN25
- Max fluid temperature: -45℃/ 180℃
- Max flow rate at 2900 rpm: 120m³/h
- Max head at 2900 rpm: 40m
- Allowable medium density range: ≤1.84g/cm3
- Allowable medium viscosity range: 365cSt
- Power range: 0.18～185kW
- Others: available on request
Common Applications
- Refinery Industry
- Chemical Processing
- Fine Chemical Processing
- Metallurgical Industry
- Food Processing
- Fiber Processing
- Pharmaceutical
- Electroplate Industry
- Paper Industry
- Electric Power Industry
