Bathtub Air Blower, Series DXD-6E
Request a Quote
Working conditions
- Conveying medium: dry air
- Environmental temperature: ≤40℃
- Maximum working pressure: 0.1MPa
With proven product quality and performance, we are confident to offer:
- Pool equipment wholesale for distributors
- Everything needed from pool and Spa equipment to pool accessories for pool & Spa contractor
- OEM service for branded suppliers and manufacturers of pool equipment and supplies
- Manufacturing service of pool equipment and supplies for the factories with limited production capacity and product variations.
Technical data
| Model | Voltage | Power | Rotating speed(r/min) | Speed(r/min) | Noise(dB) | Insulation class | Protection grade | Gross weight(kg) | Certification | |
| KW | HP | |||||||||
| DXD-6C | 230V/50Hz/60Hz | 0.55 | 0.75 | 28000 | 50 | 70 | F | IP X5 | 2.5 | |
| DXD-6D | 115V/50Hz/60Hz | 0.55 | 0.75 | 28000 | 50 | 70 | F | IP X5 | 2.5 | |
| DXD-6E | 230V/50Hz/60Hz | 0.35 | 0.5 | 23000 | 40 | 65 | F | IP X5 | 2.5 | CE TÜVSAA |
| DXD-6F | 115V/50Hz/60Hz | 0.35 | 0.5 | 23000 | 40 | 65 | F | IP X5 | 2.5 | CSA UL |
| DXD-6G | 230V/50Hz/60Hz | 0.75 | 1.0 | 30000 | 55 | 75 | F | IP X5 | 2.5 | CE TÜVSAA |
| DXD-6H | 115V/50Hz/60Hz | 0.75 | 1.0 | 30000 | 55 | 75 | F | IP X5 | 2.5 | CSA UL |
| DXD-6I | 230V/50Hz/60Hz | 0.20 | 0.25 | 20000 | 45 | 65 | F | IP X5 | 2.5 | CE TÜVSAA |
| DXD-6J | 115V/50Hz/60Hz | 0.20 | 0.25 | 20000 | 45 | 65 | F | IP X5 | 2.5 | CSA |
Packing: 310mm×225mm×230mm Container:20＇: 1820pcs 40＇ 3800pcs
