Bottom Loading Arm with API Coupler

Request a Quote

View All: http://loadingarmsystem.com/1-2-3-bottom-loading-arm-with-api-coupler.html

These bottom loading arms are used to load and unload road and railway tankers for a range of industrial fluids at liquid transfer terminals. The API coupler allows for fast connection and leak-free transfer of fluids, while ensuring safe operation.

Specifications

Nominal diameter: DN50～DN100
Design pressure: 0.1MPa～1.0MPa
Design temperature: -30℃～ 100℃
Pipeline material: carbon steel/stainless steel/aluminum alloy

Features

This loading arm can be directly mounted on the ground foundation, offering the advantages of compact structure and small footprint;
Rational layout allows for smooth operation without interference;
Constructed with steel and aluminum alloy, providing lightweight and robust structure;
Dry disconnect coupling permits easy operations, possible risks associated with leakage or dripping during loading and unloading can be avoided;
Due to the tank is filled from the bottom, the volatilization of liquid can be minimized;
Vapor return line helps achieve zero vapor emission during the loading and unloading process;
Composite drop hose or metal drop hose is employed for flexible connection between the loading arm and the tanker;
Spring cylinder balancing system keeps the outboard arm and parts of front end counterbalanced, providing the loading arm with smooth up/down movement;
Configured with anti-static device, efficiently eliminating the static charges and stray currents caused by liquid flowing through pipes during the loading and unloading operations;
