Artificial Lawn Warp Knitting Machine
Request a Quote
GE2399 Raschel Machine
Double needle bar raschel knitting machine for producing artificial lawns and turf fabrics
Applications
Artificial lawns and turf fabrics used in running tracks, playgrounds, and shielding nets.
Features
- Artificial lawn warp knitting machine uses an oil immersed cam-linkage mechanism and a swinging knock-over comb bar.
- Raschel warp knitting machine comes with a special latch needle and an open sinker system.
- Yarn supply for the pile bars from creel.
- The warp knitting machine has functions of electronic yarn let-off and electronic fabric take-up.
Specifications
- Needle type Individual latch needle
- Gauge E3, E6, E9
- Number of bars 5 bars
- Distance between knocking-over bar 20-100mm
- Working width 100"/110"
- Max. speed 300 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| GE2399-100" | 4000×6050×3400 (excluding creel) | 24.2 (excluding creel) | 8500 (excluding creel) | 8.25 |
