Designed for performance in challenging conditions, our crawler lawn mower is equipped with a powerful 6.5-horsepower gasoline engine that offers easy starting, stable output, and dependable operation with a low failure rate—ideal for extended use in demanding environments.

Its specialized wear-resistant rubber track ensures excellent traction and durability. Built to handle tough conditions, the track system provides superior anti-skid performance, protects ground surfaces from damage, and can effortlessly climb slopes up to 20°, making it the perfect choice for uneven or sloped landscapes.

Technical Specifications
Engine model B&S
Rated power 6.5HP
Cylinder single
Intake method natural aspiration
Emissions standards EURO5/EPA
Fuel capacity 3.5L
Oil capacity 0.6L
L×W×H 1517x870x1278mm
Cargo box volume 0.22m³
Hydraulic oil No. 46# anti-wear hydraulic oil
Hydraulic oil tank capacity 7L
Grad ability 20°
Min. ground clearance 85mm
Min. turning radius 950mm
Crawler center distance 520mm
Travel speed 1.7/3.5(km/h)
Travel motor maximum torque 805Nm
Travel motor maximum working pressure 20MPa
Travel motor displacement 200cc
Travel motor brand Like Hydraulic
Vehicle weight 400kg
Maximum load 500kg
