Introduction

The SR-2030EX explosion proof oxygen analyzer has greater shell strength and smaller joint clearance between the components of the shell. The shell limits the heat generated by the circuit in normal operation and the spark and high temperature formed in fault in the sealed room. Thus, it can prevent ignition of flammable and explosive gases around it.

The SR-2030Ex explosion proof oxygen analyzer is a kind of gas analyzer system which makes use of electrochemical method to measure continuously the oxygen content in kinds of mixed gases. The analyzer uses high-performance sensors with anti-acid gases, anti-interference gas, long life and stable performance.

Main specifications
Range 0-10ppm,100ppm,1000ppm,0-100%
Scale interval 0.001
Repeatability Cv£1%FS
Zero drift £±1%FS/7D
Span drift £±1%FS/7D
Response time T90 < 15S
Sample gas flow rate 500mL/min
Preheating time No need to be perheated
Signal output 4-20mA, RS232/485
Alarm High-limit alarm, low-limit alarm
Temperature and humidity 0-45°C, 20-80%RH
Power supply 220V, 50Hz
Explosion proof degree Ex dII CT6 (Acetylene contained)
Protection degree IP65
Selection Guide
  • Type: Oxygen Analyzer SR-2030AEx

    Explosion proof and digital display

  • Type: Oxygen Analyzer SR-2030BEx

    Explosion proof and LCD display with function of trend map

Application areas

It is suitable for the continuous detection of gas concentration in chemical industry, fertilizer industry, metallurgy industry, air separation industry, areas with environmental quality and the emission of pollutants.

  • Ammonia Production Gas Analyzing
  • Chemical Industry Gas Analyzer
  • Coal Coking Gas Analyzer
  • Air Separation Gas Analysis
