Neodymium Magnets (NdFeB Magnets)
Request a Quote
Permanent magnet with high magnetic properties
Prepare to witness the extraordinary as NGYC takes magnet production to new heights with our complex and high-performance NdFeB magnets.
At NGYC, we specialize in producing complex and high-performance NdFeB magnets with unique shapes and orientations. Our products boast high residual flux density, maximum energy product, and exceptional cost-effectiveness. While NdFeB magnets offer outstanding magnetic properties, they are prone to corrosion and require plating. In addition, they have a low Curie temperature and high temperature coefficient.
Applications- Automotive Industry: Drive motors, generators, measurement instruments, electric motors for hybrid and electric vehicles, spindles, and stepper motors.
- Medical Industry: Magnetic resonance imaging (MRI), magnetic levitation, medical pumps, electronic medical devices, and more.
- Industrial Machinery: Waveguides, generators, measurement instruments, magnetic levitation, magnetic drives, magnetic resonance, and various other fields.
Grade | Remanence | Coercivity | Intrinsic Coercivity | Max. Energy Product | Max. Working Temperature | ||||
Br | Hcb | Hcj | (BH)max | TW | |||||
mT | KGs | KA/m | KOe | KA/m | KOe | KJ/m3 | MGOe | ℃ | |
N35 | 1170-1220 | 11.7-12.2 | ≥868 | ≥10.9 | ≥955 | ≥12 | 263-287 | 33-36 | ≤80℃ |
N38 | 1220-1250 | 12.2-12.5 | ≥899 | ≥11.3 | ≥955 | ≥12 | 287-310 | 36-39 | ≤80℃ |
N40 | 1250-1280 | 12.5-12.8 | ≥907 | ≥11.4 | ≥955 | ≥12 | 302-326 | 38-41 | ≤80℃ |
N42 | 1280-1320 | 12.8-13.2 | ≥915 | ≥11.5 | ≥955 | ≥12 | 318-342 | 40-43 | ≤80℃ |
N45 | 1320-1380 | 13.2-13.8 | ≥923 | ≥11.6 | ≥955 | ≥12 | 342-366 | 43-46 | ≤80℃ |
N48 | 1380-1420 | 13.8-14.2 | ≥923 | ≥11.6 | ≥955 | ≥12 | 366-390 | 46-49 | ≤80℃ |
N50 | 1400-1450 | 14.0-14.5 | ≥955 | ≥12 | ≥876 | ≥11 | 392-406 | 48-51 | ≤80℃ |
N52 | 1430-1480 | 14.2-14.8 | ≥876 | ≥11 | ≥876 | ≥11 | 398-422 | 50-53 | ≤80℃ |
N54 | 1450-1500 | 14.6-15.2 | ≥876 | ≥11 | ≥876 | ≥11 | 414-438 | 52-55 | ≤70℃ |
35M | 1170-1220 | 11.7-12.2 | ≥868 | ≥10.9 | ≥1114 | ≥14 | 263-287 | 33-36 | ≤100℃ |
38M | 1220-1250 | 12.2-12.5 | ≥899 | ≥11.3 | ≥1114 | ≥14 | 287-310 | 36-39 | ≤100℃ |
40M | 1250-1280 | 12.5-12.8 | ≥923 | ≥11.6 | ≥1114 | ≥14 | 302-326 | 38-41 | ≤100℃ |
42M | 1280-1320 | 12.8-13.2 | ≥955 | ≥12.0 | ≥1114 | ≥14 | 318-342 | 40-43 | ≤100℃ |
45M | 1320-1380 | 13.2-13.8 | ≥995 | ≥12.5 | ≥1114 | ≥14 | 342-366 | 43-46 | ≤100℃ |
48M | 1370-1430 | 13.7-14.2 | ≥1027 | ≥12.9 | ≥1114 | ≥14 | 366-390 | 46-49 | ≤100℃ |
50M | 1400-1450 | 14.0-14.5 | ≥1035 | ≥13.0 | ≥1114 | ≥14 | 382-406 | 48-51 | ≤100℃ |
52M | 1430-1480 | 14.3-14.8 | ≥1043 | ≥13.1 | ≥1114 | ≥14 | 398-422 | 50-53 | ≤100℃ |
35H | 1170-1220 | 11.7-12.2 | ≥868 | ≥10.9 | ≥1353 | ≥17 | 263-287 | 33-36 | ≤120℃ |
38H | 1220-1250 | 12.2-12.5 | ≥899 | ≥11.3 | ≥1353 | ≥17 | 287-310 | 36-39 | ≤120℃ |
40H | 1250-1280 | 12.5-12.8 | ≥923 | ≥11.6 | ≥1353 | ≥17 | 302-326 | 38-41 | ≤120℃ |
42H | 1280-1320 | 12.8-13.2 | ≥955 | ≥12.0 | ≥1353 | ≥17 | 318-342 | 40-43 | ≤120℃ |
45H | 1320-1370 | 13.2-13.7 | ≥973 | ≥12.3 | ≥1353 | ≥17 | 342-366 | 43-46 | ≤120℃ |
48H | 1370-1420 | 13.7-14.2 | ≥995 | ≥12.5 | ≥1353 | ≥17 | 366-390 | 46-49 | ≤120℃ |
50H | 1400-1450 | 14.0-14.5 | ≥1003 | ≥12.6 | ≥1353 | ≥17 | 382-406 | 48-51 | ≤150℃ |
35SH | 1170-1220 | 11.7-12.2 | ≥876 | ≥11.0 | ≥1592 | ≥20 | 263-287 | 33-36 | ≤150℃ |
38SH | 1220-1250 | 12.2-12.5 | ≥907 | ≥11.4 | ≥1592 | ≥20 | 287-310 | 36-39 | ≤150℃ |
40SH | 1250-1280 | 12.5-12.8 | ≥939 | ≥11.8 | ≥1592 | ≥20 | 302-326 | 38-41 | ≤150℃ |
42SH | 1280-1320 | 12.8-13.2 | ≥963 | ≥12.1 | ≥1592 | ≥20 | 318-342 | 40-43 | ≤150℃ |
45SH | 1320-1380 | 13.2-13.8 | ≥979 | ≥12.3 | ≥1592 | ≥20 | 342-366 | 43-46 | ≤150℃ |
48SH | 1370-1430 | 13.7-14.3 | ≥1011 | ≥12.7 | ≥1592 | ≥20 | 366-390 | 46-49 | ≤150℃ |
28UH | 1040-1080 | 10.4-10.8 | ≥796 | ≥9.6 | ≥1990 | ≥25 | 207-231 | 26-29 | ≤180℃ |
30UH | 1080-1130 | 10.8-11.3 | ≥812 | ≥10.2 | ≥1990 | ≥25 | 223-247 | 28-31 | ≤180℃ |
33UH | 1130-1170 | 11.3-11.7 | ≥852 | ≥10.7 | ≥1990 | ≥25 | 247-271 | 31-34 | ≤180℃ |
35UH | 1170-1220 | 11.7-12.2 | ≥860 | ≥10.8 | ≥1990 | ≥25 | 263-287 | 33-36 | ≤180℃ |
38UH | 1220-1250 | 12.2-12.5 | ≥899 | ≥11.3 | ≥1990 | ≥25 | 287-310 | 36-39 | ≤180℃ |
40UH | 1250-1280 | 12.5-12.8 | ≥939 | ≥11.8 | ≥1990 | ≥25 | 302-326 | 38-41 | ≤180℃ |
42UH | 1280-1320 | 12.8-13.2 | ≥963 | ≥12.1 | ≥1990 | ≥25 | 318-342 | 40-43 | ≤180℃ |
45UH | 1320-1380 | 13.2-13.8 | ≥979 | ≥12.3 | ≥1910 | ≥24 | 342-366 | 43-46 | ≤180℃ |
28EH | 1040-1080 | 10.4-10.8 | ≥780 | ≥9.8 | ≥2388 | ≥30 | 207-231 | 26-29 | ≤200℃ |
30EH | 1080-1130 | 10.8-11.3 | ≥812 | ≥10.2 | ≥2388 | ≥30 | 223-247 | 28-31 | ≤200℃ |
33EH | 1130-1170 | 11.3-11.7 | ≥836 | ≥10.5 | ≥2388 | ≥30 | 247-271 | 31-34 | ≤200℃ |
35EH | 1170-1220 | 11.7-12.2 | ≥876 | ≥11.0 | ≥2388 | ≥30 | 263-287 | 33-36 | ≤200℃ |
38EH | 1220-1250 | 12.0-12.5 | ≥899 | ≥11.3 | ≥2388 | ≥30 | 287-310 | 36-39 | ≤200℃ |
40EH | 1250-1280 | 12.5-12.8 | ≥923 | ≥11.6 | ≥2388 | ≥30 | 302-326 | 38-41 | ≤200℃ |
42EH | 1280-1320 | 12.8-13.2 | ≥931 | ≥11.7 | ≥2388 | ≥30 | 318-342 | 40-43 | ≤200℃ |
28AH | 1040-1080 | 10.4-10.8 | ≥787 | ≥9.9 | ≥2624 | ≥33 | 207-231 | 26-29 | ≤230℃ |
30AH | 1080-1130 | 10.8-11.3 | ≥819 | ≥10.3 | ≥2624 | ≥33 | 223-247 | 28-31 | ≤230℃ |
33AH | 1130-1170 | 11.3-11.7 | ≥843 | ≥10.6 | ≥2624 | ≥33 | 247-271 | 31-34 | ≤230℃ |
35AH | 1170-1220 | 11.7-12.2 | ≥876 | ≥11.0 | ≥2624 | ≥33 | 263-287 | 33-36 | ≤230℃ |
38AH | 1220-1250 | 12.2-12.5 | ≥899 | ≥11.3 | ≥2624 | ≥33 | 287-310 | 36-39 | ≤230℃ |
40AH | 1250-1280 | 12.5-12.8 | ≥923 | ≥11.6 | ≥2624 | ≥33 | 302-326 | 38-41 | ≤230℃ |
