Request a Quote
  • Push pull mortise lock with thumbturn is designed without keys. The door can be locked by inside thumbturn and unlocked from outside using a coin. This design enables a quick unlock from the outside in case of an emergency when the door is locked from inside.
  • Besides, the door’s switch status can be displayed on the door lock.
  • Japanese advanced technology is adopted for surface treatment for better color adhesion and corrosion resistance.

Color

  • Nickel plating
  • Champagne gold
  • Matte black
  • Customized colors
MG1813(ZY)-X
  • Latchbolt is actuated by inside thumbturn and unlock from outside by using a coin.
  • Lock case: Galvanized zinc steel plate
  • Lever handle: Aluminum alloy
  • Bolt: POM and zinc alloy
  • Axe distance: 72mm
  • Backset: 55mm
  • Center distance of the mounting hole: 38mm
  • Door thickness: 33-50mm
MG2812(ZY)-X
  • Switching status of the door can be displayed on the outer panel.
  • Lock case: POM
  • Lever handle: Aluminum alloy
  • Bolt: POM and zinc alloy
  • Axe distance: 58mm
  • Backset: 50mm
  • Center distance of the mounting hole: 38mm
  • Door thickness: 33-50mm
MG2813(ZY)-X
  • Latchbolt is actuated by inside thumbturn and unlock from outside by using a coin.
  • Lock case: POM
  • Lever handle: Aluminum alloy
  • Bolt: POM and zinc alloy
  • Axe distance: 58mm
  • Backset: 50mm
  • Center distance of the mounting hole: 38mm
  • Door thickness: 33-50mm
MG3813(ZF)-X
  • Latchbolt is actuated by inside thumbturn and unlock from outside by using a coin.
  • Lock case: POM
  • Lever handle: Aluminum alloy
  • Bolt: POM and zinc alloy
  • Axe distance: 28mm
  • Backset: 55mm
  • Center distance of the mounting hole: 38mm
  • Door thickness: 33-50mm
