78° Dies, H=90mm, Amada Press Brake Tooling
Request a Quote
| F 26.706 (400KN/m Max) | |
| Length | Weight |
| 508mm | 6.5KG |
| 550mm sectionalized | 7.0KG |
| F 26.708 (400KN/m Max) | |
| Length | Weight |
| 508mm | 6.5KG |
| 550mm sectionalized | 7.0KG |
| F 26.710 (500KN/m Max) | |
| Length | Weight |
| 508mm | 7.0KG |
| 550mm sectionalized | 7.6KG |
| F 26.712 (600KN/m Max) | |
| Length | Weight |
| 508mm | 8.0KG |
| 550mm sectionalized | 8.7KG |
| F 26.716 (800KN/m Max) | |
| Length | Weight |
| 508mm | 10.0KG |
| 550mm sectionalized | 10.8KG |
| F 26.720 (800KN/m Max) | |
| Length | Weight |
| 508mm | 12.0KG |
| 550mm sectionalized | 13.0KG |
| F 26.724 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 11.7KG |
| 550mm sectionalized | 12.7KG |
| F 26.730 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 14.2KG |
| 550mm sectionalized | 15.4KG |
| F 26.740 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 17.3KG |
| 550mm sectionalized | 18.4KG |
| F 26.750 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 23.0KG |
| 550mm sectionalized | 24.9KG |
| F 26.760 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 21.5KG |
| 550mm sectionalized | 23.3KG |
| F 26.780 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 27.0KG |
| 550mm sectionalized | 29.2KG |
| F 26.794 (1000KN/m Max) | |
| Length | Weight |
| 508mm | 31.5KG |
| 550mm sectionalized | 34.1KG |
