Description

In a normal pressbrake, the slide stroke can be set to stop for one time, which wastes time during the processing of complex workpieces. However, the AG II hydraulic press brake features a programmable slide stroke to stop at any time, thereby increasing the processing efficiency and making this equipment ideal for factories requiring mass production to obtain a significant financial return in a small amount of time.

The overall machine structure is made of a high-performance carbon steel that has undergone a stress relieving treatment, with a maximum pressure capacity of up to 100 tons to ensure our press brakes feature a high accuracy and strength, even under long term heavy loads. A special mark line bending function ensures our press brake finds the marking line quickly and accurately, and thus, improving the processing efficiency.

If you need CNC press brake for mass bending parts, AGN is an ideal choice as we not only provide high quality products, but professional technology and thoughtful, comprehensive services.

Machine Specification
Type 03512Ⅱ 0520Ⅱ 1030Ⅱ
PressureCapacity 350KN 500KN 1000KN
Bending Length 1200mm 2000mm 3100mm
Length of Stroke 100mm 100mm 100mm
Number of Oil Tank 1 1 3
Maximun Pressure 28.66Mpa 28.3Mpa 33.8Mpa
Speed Rise 37-47mm/sec 37-47mm/sec 37-47mm/sec
Bend 7.5-10mm/sec 7.5-9.2mm/sec 7.5-10mm/sec
Descend 47-66mm/sec 47-66mm/sec 47-66mm/sec
Motor Power 3kw 4kw 7.5kw
Oil Tank Capacity 27L 44L 65L
Weight 2200kg 3450kg 6400kg
Outside Width of Frame 1200 2000 3000
Inside Width of Frame 1020 1720 2550
Throat Depth 200 405 405
Distance between Upper and Lower Worktable 250 250 250
Daylight Opening 370 370 370
Height of Lower Worktable 990 941 1030
Total Height 2070 2100 2421
Side Plate Height 1780 1783 2106
Machine Width 1423 2192 3340
Total Width 2220 3140 4210
Total Depth 1020 1315 1436
Product Details
  • The overall machine structure is a high-performance carbon steel with rust resistant paint, giving the press brakes a high strength and long service life.
  • All major components have been subjected to stress relieving treatment.
  • The slide stroke can be manually set for a single time.
  • With the use of a forced synchronization system, parallelism is maintained between the ram and the work table to effectively guarantee the bending accuracy.
  • The hydraulic circuit is simple and easy to maintain.
  • A rolling guide is used to keep the operation process flexible and decrease noise emissions.
  • The servo driven back gauge finger is CNC controlled, ensuring the metal bending machine has a fast response and positioning.
  • The CNC controller’s rotating arm ensures a flexible operation as it rotates freely in the operation area.
Operating Features
  • Users can choose their language on the 10-inch LCD color touch screen.
  • Data variable adjustments are completed via a manual handwheel or keyboard input.
  • The calculation system is used to calculate the co-ordinates of the D axis, L axis, clamp point and bending angle.
  • The computer is equipped with an online assistance system to guide operation, prompt faults, and guide simple maintenance.
  • The back-gauge finger features a programmable retraction function to process complex units.
  • Sound prompting and indicator light flashing activate when the sheet panel is positioned in place.
  • The bottom time delay and clamping delay are set to ensure the bending process is smoother.
  • Low speed bending technology is used to protect the workpiece bending surface and prevent accidents caused by the bending process.
Accessories
  • Controller with rotating arm
  • Operating interface with mutil-language
  • Machine tool drive mechanism
  • Balance beam for guide rail slide
  • Electric cabinet
  • Hydraulic circuit
  • Hydraulic clamping system
  • Safety device
  • Fast clamps
