8kW Laser Scanner Cutting Head
LDC80
Auto focus laser cutting head for processing highly reflective metals with power ratings of up to 8kW
LDC80
Auto focus laser cutting head for processing highly reflective metals with power ratings of up to 8kW
The laser scanner cutting head is designed to provide efficient solutions for the processing of highly reflective metal sheets metals with power ratings of up to 8kW. Compared to conventional cutting heads of the same power level, our auto focus laser scanner cutting head achieves faster cutting speeds and supports greater cutting thickness, ensuring higher productivity and processing quality.
| Type | Auto Focus Fiber Laser Scanner Cutting Head |
| Model | LDC80 |
| Interface Type | QBH, QD, G5 |
| Wavelength | 1080±10nm |
| Rated Power | ≤8kW |
| Focal Length | 150mm/200mm |
| Collimation Length | 100mm |
| Focusing Range | -15mm~ 15mm / -30mm~ 30mm |
| Centering Adjustment Range | ±1.5mm |
| Focusing Speed | 100mm/s |
| Auxiliary Gas Pressure | ≤3MPa |
| Wobble Range | 0-5mm |
| Wobble Speed | 4000mm/s |
| Weight | 11.5kg |
The auto-scanning cutting head is ideal for sheet metal processing of highly reflective materials, including brass, red copper, and similar alloys.
Supports multiple cutting patterns, enables flexible switching between different geometries to meet diverse cutting process requirements, maximizing equipment value
Integrated HMI operating system simplifies control and enhances ease of operation
Full body cooling of lasers ensures stable and consistent cutting performance
Compatible with QBH/QD interfaces providing versatility for integration with different laser sources
Delivers up to 2 times higher efficiency compared to conventional cutting heads under the same conditions, with significantly increased maximum cutting thickness for highly reflective materials
| Collimating protective lens | PMD21.5T2 |
| Cutting protective lens | PMD37T7 |
| Focusing protective lens | PMD37T7 |
| Collimating lens | NF100D37 |
| Focusing lens | DF190D37 |
| Cutting protective lens seal ring | 38x30x4 |
| Focusing protective lens seal ring | 37.6x33x2.1 |
| Ceramic ring (Flat) | FC-02 |
| Ceramic ring (Pointed) | FC-40 |
| Nozzle | FSN02，FSN07 |
