C-XZB-D550×600 2000KN Transfer Type Molding Press for Rubber
Request a Quote
- Model: C-XZB-D550×600
- Heating Plate Size: 550mm×600mm
- Clamping Force: 2000 KN
Technical Specifications of Transfer Type Molding Press for Rubber
| Clamping force | 2000 KN |
| Max System Pressure | 23 MPa |
| Clamping stroke | 300 mm |
| Rapid clamping speed | ≥50 mm/s |
| Heating plate size | 550mm×600mm |
| Heating plate spacing | 180~480 mm |
| Max operating temperature of heating plate | 250 ℃ |
| Material cylinder spec | ￠90mm×290mm |
| Injection stroke | 450 mm |
| Injection pressure | 100 Mpa |
| Ejector stroke | 300mm |
| Max ejector force | 60 KN |
| Motor power | 5.5 KW |
| Heating power | 13.1 KW |
| External dimension (LxWxH) | 1900mm×2400mm×(3000~3200)mm |
| Oil tank capacity | 320 L |
Beginning its business in 1997, CHAP is one of the transfer type molding press for rubber manufacturers and suppliers. We can produce various rubber machineries, such as vacuum vulcanizing press for rubber, C-Frame Transfer type molding machine, plate rubber vulcanizing machine, custom rubber machine, and more.
Located in Ningbo City, we are surrounded by transportation facilities like highways, airports, and sea ports. This allows us to conveniently transport our products and effectively reduce our customers' freight charges. If you are interested in our products, please do not hesitate to . We look forward to doing business with you.
