C-XZB-D850X1000 4000KN Rubber Transfer Molding Machine

C-XZB-D850X1000 4000KN Rubber Transfer Molding Machine
Request a Quote

Applications
With compact structure and high level of automation, CHAP rubber transfer molding machine is widely used for producing rubber products with metal insert, complex shape, big cross section and thick wall.

Technical Specifications of Rubber Transfer Molding Machine

C-XZB-D850×1000/4000
Clamping force 4000 KN
Clamping stroke 400 mm
Rapid clamping speed ≥40 mm/s
Heating plate size 850mm×1000mm
Heating plate spacing 400~500 mm
Max operating temperature of heating plate 250 ℃
Material cylinder spec ¢130mm×445mm
Injection stroke 680 mm
Injection pressure 80 Mpa
Ejector stroke 400 mm
Max ejector force 120 KN
Motor power (7.5+4) KW
Heating power 44.4 KW
External dimension (LxWxH) 2500mm×3500mm×(4800~5200)mm
Oil tank capacity 500 L

CHAP is a major manufacturer and supplier of rubber transfer molding machine in China. Our company is located in Ningbo City which provides us with convenient transportation. Therefore, we can deliver our plate rubber vulcanizing machine, thermoset plastic transfer molding machine, custom rubber machine, etc. to you in time. These products are manufactured in conformity with the standard of ISO, so our worldwide customers can feel secure in inquiring and ordering. In addition, we establish long term cooperative relationship with material suppliers, which helps reduce our material purchasing cost. Therefore, we can provide rubber machinery at reasonable prices. If you have any need, please contact us directly. We look forward to cooperating with you.
