Pneumatic Diaphragm Valve, MV303 Manufacturer

Pneumatic Diaphragm Valve, MV303

Request a Quote

View All: http://plasticsvalves.com/1-3-pneumatic-diaphragm-valve-mv303.html

Pneumatic Actuated Diaphragm Valve for Chemical Process

MV303 pneumatic diaphragm valves features innovative valve flow passage design and improved mechanical structure, leading to larger flow rate. Configurated with PN 10 pressure level, this diaphragm valve is suitable for applications in water piping systems and chemical fluid systems.

Specifications

Features

Easy installation and maintenance

Independent actuator for easy replacement and dismounting
With pilot operated solenoid valve mounting base for quick installation
Position indicator configured with protective shield adapted to outdoor and harsh working environments
Absence of metal parts exposed to the external environment to prevent any risk of corrosion
Excellent lubrication performance and maintenance free
Air inlet direction is optional at 90°intervals.
Perfect for installation in limited space
Same installation length as market standard valves

Outstanding safety

Insert-molded threaded connection suitable for different installation strengths.
Valve flow passage and pneumatic actuator overpressure design for improved safety
Smoothened valve flow passage design for better protection from water hammer

Excellent flexibility in configuration

Connection: flange, spigot, true union (socket or spigot)
Connection standard: metric, US, JP
Diaphragm: EPDM, FPM, EPDM-PTFE
Valve body: PVC-U, PVC-C, PP-H, PVDF, PP-Natural
PP-H, PVDF pneumatic diaphragm valves offer oil-free options

Best flow control performance

Smoothened flow path profile leads to lower loss of pressure and double flow rate
Linear flow characteristics for more accurate fluid control
Suitable for media containing a small number of particles and solids

Application

Water treatment
Power industry
Steel
Metallurgy
Petrochemical industry
Chemical engineering
Marine engineering
PV
Nuclear
Wind energy
Chlor-Alkali
