Shelf Type Film Slitting Machine, ZTM-G 2000 Manufacturer

Shelf Type Film Slitting Machine, ZTM-G 2000

Request a Quote

View All: http://converting-machinery.com/1-3-shelf-type-film-slitting-machine.html

Video

The ZTM-G 2000 shelf type film slitting machine is mainly applied to slit cellophane, PET, OPP, CPP, PS, PVC, optical materials, film roll, etc.

Specifications

Details

Side view
4-roll or 6-roll independent shaftless rewind stand
Italy RE pneumatic brake is used as unwind tension's actuator
Germany brand E L web guide control device is used as EPC
Automatic roll unloading system for removing finished rolls
Optional pneumatic circular knife
PLC touch screen at frond and back
4 sets of servo motors are used as rewind tension's actuator. PLC is used to achieve a constant tension control
Shaftless unwind stand

Machine body

Machine’s main body adopts cast iron and steel structure, the cast iron is treated by secondary processing;
Main driving roller adopts seamless steel pipe which is subjected to tempering, surface hardening, chrome plating, dynamic balance and mirror surface treatment;
Material guide rollers are aluminum rollers that are hard chrome plated and specially treated to avoid material from scratching, and rubber rollers that are made from nitrile-butadiene rubber;
Driving mode of main body adopts Chinese famous brand synchronizing wheel and belt;

Unwinding unit

Unwind unit adopts separate structure;
It adopts movable bracket with linear guide rail, greatly decreasing the friction when EPC is working;
Air chuck clamps the parent roll in a rapid and efficient manner, requiring only one person to operate;
Balance adjustment device can finely adjust left and right, forward and backward through hand wheel;
Italy RE pneumatic brake is used as unwind tension's actuator. PLC system is adopted to control the unwind tension;
EPC uses Germany brand E L web guide control device, it can achieve guide function by material's edge;

Rewinding unit

Adopting 4 sets of shaftless rewind station;
Lock mode adopts pneumatic control;
4 sets of servo motors are used as rewind tension’s actuator. PLC is used to achieve a constant tension control;
Each station has a rubber nip roller;
Active slitting knives are controlled by pneumatic cylinder (5 sets), can be finely adjusted;
Equipped with a vacuum-type edge trim waste reject system, removing waste edge through strong force adsorption;

Electrical components

1 Taiwanese brand DANMA servo motor is used as main motor;
1 Germany brand REXROTH servo motor drive is used as main motor drive;
4 Taiwanese brand DANMA servo motors are used as rewind motor;
4 Germany brand REXROTH servo motor drives are used as rewind motor drive;
EPC adopts analog control, driven by servo motor with ultrasonic sensor;
Imported PLC is adopted to achieve accurate and stable control, color touch screen displays intuitive and clear images; Interactive parameter setting eliminates the complicated configuration and can start the job; Before starting the job, user only needs to input the material thickness, width, density, diameter and speed parameters, and the machine will complete the tasks automatically through computer calculation;
