60 Series AC Servo Motor

Request a Quote

View All: http://motor-gearbox.com/1-4-1-60-series-ac-servo-motor.html

Product description

The 60 series AC servo motor realizes closed-loop control of position, speed and torque, thus solving the problem of loss of synchronism of stepping motor. They are suitable for machine tool, medical equipment, high precision equipment sets of printing, food, elevator, chemical, wood working industries etc.

Technical parameters

Motor model	60ST-M00630								60ST-M01330
Rated powerW	200								400
Rated line voltage V	220								220
Rated current A	1.2								2.8
Rated speedrpm	3000								3000
Rated torque N.m	0.637								1.27
Max torqueN.m	1.91								3.9
Rotor inertiaKg.m²	0.175x10-4								0.29x10-4
Weight kg	1.16								1.63
Encoder line numberPPR	Class F
Insulation grade	2500
IP grade	IP65
Service environment	Temperature: -20℃ ~ + 40℃ Humidity: relative humidity＜90% (frost free condition)
Winding socket	Winding wire				U (red)			V (yellow)			W (blue)			PE (yellow green/black)
	Socket No.				1			2			3			4
Encoder socket	Signal wire	5V	0V	B+	Z-	U+	Z+	U-	A+	V+	W+	V-	A-	B-	W-	PE
	Socket No.	2	3	4	5	6	7	8	9	10	11	12	13	14	15	1

Model code:
(Take 60 - ST - M - 00630 Z1 as an example.)
60: frame No.;
ST: sine drive wave;
M: code of feedback components which is M-photoelectric encoder;
00630: code of performance parameters. The first three numbers indicates the rated torque and the after two indicates rated speed. For example, 00630 means that the rated torque is 0.6N.m and the rated speed is 3000rpm.
Z1: derived code. Z1 means magnetic brake and Z2 means permanent magnet brake.

Outline and installation dimension

Dimension figure

Motor model	A	B	C	D	E	F	6	H	I	T	M	N	P	S	L*	L2*
60ST-M00630	2	20	2	⌀14	30	5	16	72	8	3	⌀70	⌀50	60	⌀5.5	127	175
60ST-M01330	2	20	2	⌀14	30	5	16	72	8	3	⌀ 70	⌀50	60	⌀5.5	152	200

Note: the unit is mm. L is the electric motor length without brake. L2 is the electric motor length with permanent magnet brake.

ZHOUYI is a leading 60 series AC servo motor manufacturer and supplier, specializes in design and manufacture industrial electric motors, speed reducers and gearboxes since 1990. With manufacturing process in accordance to IEC standard, our company is committed to providing quality AC electric motors with a variety of model selections and configurations, to meet specific needs for your equipment and machines.
