Smart UPS On-line 15kVA RM/RT 400V

Request a Quote

Website: http://siconelectric.com/1-4-3-smart-ups-on-line-15kva-rm-rt-400v.html

This is a smart on-line UPS system with module power of 15kVA. The input/output method options are 1/1, 1/3, 3/1, 3/3 phase mode, and support rack-mount or tower mounting options.

DSP-15kVA UPS System

Module power: 15kVA
Input/output phase mode: 1/1, 1/3, 3/1, 3/3
Mounting options: Rack-mount or tower

UPS System Technical Parameters

Battery parameter

Battery voltage	±240V
Battery current	31.3A
Maximum charging current	4A

AC input

Input rated voltage	One phase three-line 220V, Three-phase four-line grounding line 380V
Input voltage range	176VAC-264VAC, 304VAC-456VAC
Input power factor	0.99(100% linear load)
Input frequency	40-70Hz
Frequency Synchro range	45Hz-56Hz
Frequency Synchro rated	0.5-2Hz/s

AC output

AC output voltage	Single phase: 220VAC/230VAC/240VAC Three phase: 380VAC/400VAC/415VAC
Output power factor	0.8
Output frequency	50/60Hz
Output frequency stability	±0.1%
Output THDU	3%(liner load)
Output voltage accuracy	± 2%
Transient range	±5% (load changing 0%~100%~0%)
Transient duration	20 ms
Peak factor	3:1(rated input)
Output delay at power-on	5-60S
overload	1min 125% rated load
Overall efficiency	≥ 93%
Transfer time Bypass-Inverter	≦ 2ms
Parallel current unbalancedness	5%( ＞50% load )
Communication	RS232/USB / SNMP (standard); SNMP (optional)

Other

Dimension (WDH)mm	430622132mm
Weight (kg)	25kg
Mounting	Rack-mount/tower
Acoustic noise	≦ 58dB
Heat-dissipating method	Force air cooling
Protection level	IP20
Enclosure material	Cladding aluminum galvanized, cold-rolled steel sheet, panel: plastic spraying processing
