Underground Scaler, XMPYT-60/325 (Mine Scaling Machine)

Underground Scaler, XMPYT-60/325  (Mine Scaling Machine)
Underground Scaler, XMPYT-60/325  (Mine Scaling Machine)
Underground Scaler, XMPYT-60/325  (Mine Scaling Machine)
Underground Scaler, XMPYT-60/325  (Mine Scaling Machine)
Request a Quote

XMPYT-60/325 underground scaler has been engineered for scaling work in drifts, tunnels and caverns. The hydraulic scaling machine provides both quality scaling and high safety, productivity and effectiveness, which greatly speeds up scaling works and the entire excavation process.

This mining scaler features folding scaling boom with hydraulic hammer driven by rotary cylinder, which can be used for scaling on face, roof, side wall and floor in underground mines or tunnels. In addition, the hydraulic system of the scaling vehicle is equipped with load-sensing control, providing for low fuel consumption, stable steering, and accurate positioning.

Technical Specifications
General Overall dimensions
(L×W×H)
7700×1650×2600 mm
Retractable length (boom) 6600 mm
Max. scaling height 6060 mm
Hydraulic hammer swing angle 50° - up, 65° - down; ±60° (left/right)
Boom swing angle ±30°
Gradability 14
Turning radius inside 2900mm, outside 4900 mm
Rod diameter ⌀ 53
Hydraulic breaker Impact rate 550-1100 bpm
Rated power 60 kW
Scaling Coverage
