12T Telescopic Boom Crawler Crane, STSQ12L
Request a Quote
Our 12-ton telescopic boom crawler crane is equipped with hydraulic outrigger, greatly increasing the loading efficiency because that it doesn't need for loading ramp. The features of compact structure and small turning radius make the crawler crane suitable for muddy ground and mountainous terrain. The telescopic boom can reach 20 meters when it is fully extended. The 360-degree rotating platform makes daily operation and maintenance easier.
Features
- Excavator crawler track is adopted for its good adaptability and gripping ability, allowing for moving through muddy ground and mountainous terrain;
- Able to lift and move in hard-to-access areas, ground clearance of 350mm;
- Customer-specific double-section hydraulic outrigger eliminates the need for vehicle loading ramp, ensuring high loading efficiency;
- Max. loading capacity
- 12t
- Max. lifting height
- 20m
- Outrigger span (longitudinal* transversal)
- 4.59m*4.65m
- Outrigger span
- 4.65m*4.59m
- Boom
- 5 sections (5m per section)
- Dimensions
- 6.75m*2.3m*2.55m
- Engine model
- Huadong 4108
- Engine power
- 88kW
- Gearbox
- planetary reducer
- Slewing speed
- 2.8r/min
- Crane weight
- 14000kg
