Application
The MLSE series volumetric 3 layer plastic sheet co-extrusion line specializes in the mass-production of plastic sheets out of PP, PE, PS, HIPS, and other materials. This equipment can simultaneously extrude 3 layers of sheets, with a maximum extrusion capacity of 450kg/h. The composite distributor matches with the extrusion die to make different plastic raw materials that are combined in a uniform and stable manner, with the proportions of the composite sheet layers arbitrarily adjustable.

Siemens display screen

This volumetric 3 layer plastic sheet co-extrusion unit can also be equipped with a measuring pump, PLC control system, 3-roller independent control system and the high quality accessories from Siemens, JCTIMES, SMC and other brands. Then, it will feature a higher level of automation, a quick response and a stable operation in order to meet customer requirements for performance.

This volumetric 3 layer sheet co-extrusion line produced plastic sheets are used in cup making machines, thermoplastic forming machines, flip molding machines, multi-station forming machines and other plastic thermoforming equipment in order to manufacture multi-colored plastic packaging products, including cups, bowls and more.

Production technique
This inclined volumetric 3 layer plastic sheet co-extrusion line consists of the extrusion machine, 3-rolled calender, traction winder and electrical control cabinet.

The process includes:
Feeding → Heating → Extrusion → Calendering → Cooling → Winding

Technical parameter
MLSE 90/50 800 A, B, C Co-extrusion line
Sheet width Sheet thickness Screw diameter Length-diameter ratio of the screw Main motor power Maximum output Total power Size (L*W*H)
≤700mm 0.2-2.0mm Φ90mm,Φ50mm 35:1 55kw, 15kw 200kg/h 110kw 13.0*2.0*3.0m
MLSE100/70 900 A, B, C Co-extrusion line
Sheet width Sheet thickness Screw diameter Length-diameter ratio of the screw Main motor power Maximum output Total power Size (L*W*H)
≤800mm 0.2-2.0mm Φ100mm,Φ70mm 35:1 75kw, 22kw 280kg/h 150kw 14.0*2.0*3.2m
MLSE110/80 900 A, B, C Co-extrusion line
Sheet width Sheet thickness Screw diameter Length-diameter ratio of the screw Main motor power Maximum output Total power Size (L*W*H)
≤800mm 0.2-2.0mm Φ110mm,Φ80mm 35:1 90kw, 37kw 350kg/h 200kw 15.0*2.1*3.2m
MLSE120/90 1000 A, B, C Co-extrusion line
Sheet width Sheet thickness Screw diameter Length-diameter ratio of the screw Main motor power Maximum output Total power Size (L*W*H)
≤900mm 0.2-2.0mm Φ120mm, Φ90mm 35:1 110kw, 55kw 450kg/h 250kw 16.0*2.2*3.5m

ELITE Plastics is manufacturing plastic forming and sheet extrusion equipment, such as sheet extrusion line for various plastic materials like PE, PPT, PS, PET, etc. and offers the custom thermoplastic machines and thermoforming equipment and other plastic thermoforming machines. With almost 20 years experiences of manufacturing plastic machines, ELITE Plastics can provide any client good plastic thermoplastic and extrusion machines.
