5454/5154 Aluminum Alloy
Request a Quote
5454/5154 aluminum sheets/plates available size range
- Thickness: 0.2-200mm
- Width: 30-2500mm
- Length: 500-13000mm
- Thickness: 0.2-6.35mm
- Width: 500-2500mm
Application
5454/5154 aluminum alloy is widely used in the manufacture of welded structures, storage tanks, pressure vessels, truck dump bodies, tanker trucks, exhaust stacks, chemical handling tanks on vessels, marine & off-shore applications, etc.
Aluminum alloy state, size and mechanical properties| Alloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
| Chinese standard | Value | ||||
| 5454、5154 | O H111 | ＞0.20-0.50 | 215-275 | 215-275 | ≥12 |
| ＞0.5-1.50 | ≥13 | ||||
| ＞1.5-3.0 | ≥15 | ||||
| ＞3.0-6.0 | ≥17 | ||||
| ＞6.0-12.50 | ≥18 | ||||
| ＞12.5-50.0 | - | ||||
| H22 H32 | ＞0.2-0.50 | 250-305 | 250-305 | ≥5 | |
| ＞0.5-1.50 | ≥6 | ||||
| ＞1.5-3.0 | ≥7 | ||||
| ＞3.0-6.0 | ≥8 | ||||
| H24 H34 | ＞0.2-0.50 | 270-325 | 270-325 | ≥4 | |
| ＞0.5-1.50 | ≥5 | ||||
| ＞1.5-3.0 | ≥6 | ||||
| ＞3.0-6.0 | ≥7 | ||||
| H26 H36 | ＞0.2-1.50 | 290-345 | 290-345 | ≥3 | |
| ＞1.5-3.0 | ≥4 | ||||
| ＞3.0-6.0 | ≥5 | ||||
| H112 | 6.0-12.50 | ≥220 | ≥220 | ≥8 | |
| ＞12.5-40.0 | ≥215 | ≥215 | - | ||
| ＞40.0-120.0 | - | ||||
