SK Collet
Request a Quote
The SK collet is widely used in high-speed milling, drilling and reaming. It has an 8°cone angle, the smaller the cone angle, the higher the concentricity of collet. When clamping, the SK collet will produce strong force, making it easier to be put into tool carrier, which will increase the accuracy of manufacturing to twice than that of ER collet. If you do not know clearly which type of SK collet to choose, please contact us. Our professional salesman will give you a specific technical suggestion according to your machine type.
Technical parameter
| model | D | Collapsible |
| SK6 | 2, 2.5, 3 | 0.25 |
| SK6 | 3.5,4,4.5,5,5.5,6 | 0.5 |
| SK10 | 2, 2.5, 3 | 0.25 |
| SK10 | 3.175 | 0.475 |
| SK10 | 3.5, 4, 4.5, 5, 5.5, 6,6.5, 7, 7.5, 8, 8.5,9,9.5,10 | 0.5 |
| SK16 | 3 | 0.25 |
| SK16 | 3.175 | 0.475 |
| SK16 | 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7,7.5, 8,8.5, 9, 9.5,10,10.5,11,11.5,12,12.5,13, 13.5,14, 14.5,15,15.5,16 | 0.5 |
| SK25 | 6, 8, 10,12,14,16,16.5, 17,17.5,18,18.5,19,19.5, 20, 20.5, 21, 21.5, 22, 22.5, 23, 23.5, 24, 24.5, 25 | 0.5 |
| Model | L | L1 | L2 | d | dl | d2 |
| SK06 | 25.7 | 17.5 | 4 | 9.26 | 10.5 | 7.5 |
| SK10 | 32 | 22 | 5 | 13.7 | 15.6 | 12 |
| SK16 | 46 | 32 | 8 | 21 | 24.6 | 18.8 |
| SK25 | 58 | 43 | 8.5 | 31 | 35.6 | 28.9 |
