The ZF series external concrete vibrator has been widely used in various fields for concrete compaction or various jobs wherever vibration source is required, such as belt conveying, materials sieving, product packaging, prefabricated parts production, etc.

Three-phase power supply, 220V/380V, 50Hz/60Hz
4 poles, 1500/1800rpm

Optional Models
  • ZF300-25
  • ZF25-25
  • ZF37-25
Model Housing material Max. centrifugal force (kN) Vibration frequency (vpm) Amplitude (half value) (mm) Amplitude (total value) (mm) Rated current (A) Rated output power (kW) Rated input power (kW) Net weight (kg)
ZF12-25 Aluminium 2 1500/1800 6.5 13 0.88/0.51 0.12 0.25 11
ZF18-25 Aluminium 3 1500/1800 9.35 18.7 1.14/0.66 0.18 0.28 13
ZF25-25 Aluminium 5 1500/1800 7 14 1.21/0.70 0.25 0.45 23
ZF37-25 Aluminium 7.5 1500/1800 9.5 19 1.56/0.90 0.37 0.54 27
ZF300-25 Cast steel 50 1500/1800 9.5 19 10.90/6.30 3 3.56 170
Mounting Specification
Model Mounting dimension (mm) Overall dimension (mm)
A B N×Φd H HA AB BB HD L
ZF12-25 120/145 110/90 8×Φ11 68 18 175 136 165 280
ZF18-25 120/145 110/70-90 8×Φ11 79 18 175 136 178 296
ZF25-25 155 105 4×Φ13 86 19 192 164 205 370
ZF37-25 170 120 4×Φ17 93.5 20 221 188 216 390
ZF300-25 350 170 4×Φ33 165 50 430 235 335 490
