  • PNEV40
  • Cradle lug bracket
  • Vibrator mounting bracket with bolt
Recommended Application

This PNEV40 external pneumatic concrete vibrator can be quick mounted on cradle lug bracket or using bolt for fastening on vibrator mounting bracket, ensuring a firm and compact structure while getting a better appearance. Besides, compressed air is used as power source for the concrete vibrator, and there is no need for electrical connection, so it is suitable for construction occasions wherever explosion-proof is required.

Technical Data
Model PNEV40
Air pressure (MPa) 0.6
Centrifugal force (kN) 40
Vibration amplitude (mm) 2.1
Vibration frequency (vpm) 15000
Air consumption (L/min) 1630
Weight (kg) 14.5 (without mounting bracket)
Mounting Quick mounting
Characteristics of External Pneumatic Concrete Vibrator
  • The design of compressed-air driving and a safe opening method of compressed-air couplings can ensure the safe and efficient operation of the vibrator.
  • The vibrator hose clamps and casing are all made of high quality carbon steel and have been treated by heat treatment process, which can ensure the long service life of the vibrator.
Mounting Specification
Mounting dimension (mm) Overall dimension (mm)
A B N×Φd H HA AB BB HD L
124 170 4×Φ22 93 10 164 235 218 243.5
