Oil-Seal Machine, XLB-D350X400_DZ1000
Request a Quote
This product has been discontinued and removed from our shelves.
Features - CHAP oil-seal machine is reliable, efficient and energy-saving.
- It is configured with a computerized electro-hydraulic proportional control system for high degree of automation.
- Our oil-seal machine utilizes a large screen LCD to display parameters, resulting in clear visual effects and ease of operation.
- Vacuum components from world famous brands help ensure the efficiency and reliability of the vacuum system.
- Fast mould opening and closing results in high production efficiency.
- The automatic mould in/out mechanism and 3RT injector system not only effectively reduces the labor intensity but also avoids man-made damage to the mould.
- Users can choose Siemens or Mitsubishi PLC control, 5.7-inch touch screen.
| XLB-D350X400_DZ1000 Oil-Seal Machine | |
| Clamping force | 1000 KN |
| Clamping stroke | 60 mm |
| Rapid clamping speed | ≥20 mm/s |
| Heating plate size | 350 mm×400 mm |
| Heating plate spacing | / |
| Max operating temperature of heating plate | 250 ℃ |
| Ejector stroke | / |
| Max daylight | 140 mm |
| Injection stroke | / |
| Injection pressure | / |
| Upper mould release distance | 150 mm |
| Open mould distance | 190 mm |
| Moving mould stroke | 590 mm |
| Down stroke | 100 mm |
| Vacuum cover stroke | 75 mm |
| Max mould thickness | 85 mm |
| Max ejector force | / |
| Motor power | 5.5 KW |
| Heating power | 7.2 KW |
| External dimension (LxWxH) | 2500mm×1300mm×2000mm |
| Oil tank capacity | 360 L |
| Material cylinder spec. |
Founded in 2004, CHAP is a professional oil-seal machine manufacturer located in China. We can produce various rubber machineries, such as vacuum rubber vulcanizing machine, plate rubber vulcanizing machine, tire valve vulcanizing machine, custom rubber machine, and more. As a result of superior quality, economical prices and good after-sales service, our EC certified products are highly sought after by customers from Europe, South America, Southeast Asia, East Asia, and other regions. If you buy these products from our company, we can also provide you with convenient transportation, especially sea and air transportation. We sincerely hope to cooperate with you!
