ESL Brake Release Valve
Request a Quote
Hydraulic valve blocks for smooth control of scissor lift
- Modular, compact design for safe and reliable hydraulic control
- Patented design with an integrated travel counterbalance valve to improve overall platform stability
- High-efficiency construction reduces energy consumption, extending equipment operating time
Applications
Used in hydraulic scissor lift platforms, this valve block provides smooth and reliable control of emergency brake release during travel. Built for durability and safety, it ensures stable operation and contributes to the overall efficiency of the operation of lift system.
Specifications
| Pressure | 250bar |
| Flow Rate | 2mL/stroke |
| Fluid Temperature Range | -20℃～100℃ |
| Ambient Temperature Range | -20℃～80℃ |
| Oil Viscosity Range | ISO 20～400mm²/s |
| Internal Leakage | 3 ~ 5drops/min |
| Weight | 0.67kg |
