This pneumatic vacuum conveyer is used for automatic material feeding for tablet press machines, capsule filling machines, packing machines, pulverizing machines, screen machines and mixing machines. Unlike a mechanical vacuum pump, it is noiseless, maintenance-free, and features a simple structure, small volume, and easy to operate performance. Designed according to international standards, this pneumatic vacuum conveyer complies with GMP requirements.

Specifications of Pneumatic Vacuum Conveyer QVC
Model Transportation Capacity (kg/h) Air Pressure Air Consume Overall Size
(Mpa) (L/min) (mm)
QVC-1 350 0.4-0.6 180 Φ140×560
QVC-2 700 0.4-0.6 360 Φ213×720
QVC-3 1500 0.4-0.6 720 Φ290×850
QVC-4 3000 0.4-0.6 1440 Φ420×1150
QVC-5 6000 0.4-0.6 2880 Φ420×1150
QVC-6 9000 0.4-0.6 4320 Φ420×1350
