Multifunction Busbar Bender
Request a Quote
| Item number | 6221 | 6231 | |
| Model | CL2A | CL1 | |
| Drive mode | Mechanical | Hydraulic | |
| Applicable size of copper busbar(mm)(mm) | ≤125×12.5 | ≤125×12.5 | |
| Thrust(kN) | 300 | 200 | |
| Power(kW) | 3 | 1.5 | |
| Power supply(AC/V) | 380 | 380 | |
| Dimension(mm) | 935×720×905 | 675×670×1000 | |
| Weight(kg) | 235 | 140 | |
| Dies Model | Horizontal | 6221.1 | 6231.1 |
| Vertical | 6221.2 | 6231.2 | |
| Z shape | 6221.3 | 6231.3 | |
| Punch | 6221.4 | 6231.4 | |
| Cut | 6221.5 | 6231.5 | |
Uses: to bend copper and aluminum bus-bar horizontally, vertically, Z shape, and cut and punch on it
Notes: Punching dies specification: φ7, 9, 11, 13, 15, 17, 21
