Horizontal Flow Wrapping Machine
Request a Quote
Main Features
- This horizontal packing machine can set the bag length automatically, which saves on labor force.
- Dual variable frequency control system provides the packing equipment with characteristics like simple maintenance, low wearing and long service life.
- Single chip control, touch screen display, variable frequency control, user-friendly human-machine interface, etc. makes the packing machine convenient and simple for operation.
- Independent temperature control for each sealer enables the horizontal packing machine to create beautiful and tight sealing.
- The horizontal packing equipment is suitable for a wide variety of materials, including bread, biscuit, candy, mooncake, hardware parts, and so on.
Specifications
| Model | LT-250 | LT-350 | LT-450 |
| Film width | Max.250 mm | Max.350mm | Max.450mm |
| Bag-making length | 65-190 or 120-280mm | 65-190 or 120-330mm | 90-220 or 150-330mm |
| Bag-making width | 30-110mm | 50-160mm | 100-260mm |
| production height | Max.40 mm | Max.40mm | Max.60mm |
| Film roll diameter | Max.250mm | Max.320mm | Max.320mm |
| Packaging speed | 40-230bag/min | 40-230bag/min | 20-200bag/min |
| Power specification | 220V/50HZ. 2.5kW | 220V/50HZ. 2.8kW | 220V/50HZ. 4.2kW |
| Machine Dimension (L×W×H) | 3770*640*1400mm | 4020*770*1450mm | 4380*870*1500mm |
| Machine weight | 500kg | 650kg | 800kg |
