Multi-function Extraction Tank

Request a Quote

Website: http://liquidprocessplant.com/2-1-1-1-multi-function-extraction-tank.html

Stainless Steel Sanitary Tanks, Sanitary Stainless Steel Tanks & Vessels

In the multi-function extraction tank, the material can be extracted by mixing with water or an organic solvent. Our multi-function extraction tanks serve a variety of industries including pharmaceutical, food, and chemical industry.

Form

Design Pressure: atm-0.8MPa

Design Temperature: 0℃-160℃ (customized)

Treatment: mechanical polishing, sandblasting, pickling

Polishing Accuracy: internal wall 0.4μm, external wall 0.6μm

Inner Body: 304, 316L stainless steel

Jacket: 304 stainless steel

Insulated Layer: rock wool

Inlet & Outlet: quick change chuck interface, flange

Technical Parameters

Capacity (L)	Tank		Mixing
Capacity (L)	Diameter (mm)	Height (mm)	Motor Power (kW)	Mixing Speed (r/min)
2000	1300	1500	2.2	35 (helix type) or customized
3000	1600	1500	3
5000	1800	1800	4
6000	1900	2000	5.5
8000	2000	2200	7.5

Features

Our extraction tanks come in a very wide variety of sizes, ranging from 2000L to 8000L. We can design and manufacture the extraction tank as your request.
The pneumatically operated discharge gates are safe and reliable. The gate provides the maximum protection in the sudden loss of power or gas.
The quick change chuck interface can be customized with your specific requirements such as polishing or wiredrawing.
