Vertical Pelletizing Extruder (Cooling Type)

Request a Quote

Website: http://powerhandling-en.com/2-1-1-3-vertical-pelletizing-extruder.html

Pharma extruder with an integrated cooling mechanism to handle heat-sensitive materials for pharmaceutical products and drugs

The cooling-type vertical pelletizing extruder is an advanced model developed based on the standard vertical design, enhanced with integrated cooling, anti-slipping, and precise temperature control functions. It is engineered for processing temperature-sensitive materials used in pharmaceutical production.

Specifications

Model	CXJ-40	CXJ-80	CXJ-120	CXJ-150	CXJ-200	CXJ-300	CXJ-400
Min. feeding weight	0.15kg	0.3kg	0.5kg	0.5kg	1kg	2kg	2kg
Production capacity (based on Ø 0.8mm)	≤50	≤80kg/h	≤120kg/h	≤150kg/h	≤260kg/h	≤360kg/h	≤500kg/h
Die aperture	Ø0.4–3.0mm	Ø0.5–3.0mm	Ø0.5–3.0mm	Ø0.5–3.0mm	Ø0.5–3.0mm	Ø0.6–3.0mm	Ø0.6–3.0mm
Power supply	380V, 50Hz
Rotation speed	5–95rpm
Material return ratio	≥99%
Noise level	＜45dB	＜45dB	＜45dB	＜60dB	＜60dB	＜60dB	＜60dB
Overall dimensions (L×W×H)	86×70×16 cm	95×80×160cm	135×100×162cm	135×110×162cm	150×110×165cm	165×115×165cm	165×120×165cm
Weight	380kg	600kg	800kg	1000kg	1200kg	1500kg	1800kg

Features

Efficient temperature control
The cooling system maintains the extrusion zone within a temperature rise of ≤5 °C (with chilled water) or ≤10 °C (with tap water), ensuring stable operation without heat buildup.
Stable material feeding
The extruder prevents material slippage during processing, maintaining uniform extrusion and consistent product quality.
Reliable sealing and easy maintenance
Equipped with a main inlet and outlet for cooling water, featuring quick-connect couplings for easy setup and disassembly without leakage.
Continuous production for heat-sensitive materials
Enables efficient continuous extrusion for temperature-sensitive compounds, improving productivity and expanding material compatibility.
Automated temperature monitoring
The system continuously measures and regulates the material temperature in real time, ensuring optimal process conditions.

Applications

Ideal for the production of heat-sensitive pharmaceutical pellets and sustained-release formulations such as ibuprofen extended-release micro-pellets, as well as other active pharmaceutical ingredients (APIs) requiring precise temperature control during extrusion.

Compatible Equipment

This extruder is typically paired with a spheronizer to form a complete pelletizing system.

For powder processing, we also provide a .
