Horizontal Pelletizing Extruder

Request a Quote

Website: http://powerhandling-en.com/2-1-2-horizontal-pelletizing-extruder.html

Radial screw extruder for producing cylindrical extrudates through perforated screens

In this horizontal extrusion system, the pre-mixed wet mass is driven by a screw feeder into the extrusion chamber, where it is compressed through a perforated screen to form dense, uniform cylindrical strands of varying lengths. The extruder is composed of a motor, gearbox, transmission assembly, feed hopper, screw feeder, extrusion chamber, perforated plate, screw cap, control system, and a rigid support frame.

Specifications

Model	E-10	E-60	E-120	E-200
Production capacity (based on Ø 0.8mm)	≤6kg/h	≤40kg/h	≤80kg/h	≤160kg/h
Min. feeding weight	0.2kg	0.5kg	1.2kg	2.0kg
Die aperture	0.4–3.5mm
Rotation speed	5–120rpm
Material return ratio	≥99%
Power supply	380V, 50Hz
Motor power	1.5kW	3kW	4kW	7kW
Noise level	＜45dB	＜45dB	＜45dB	＜50dB
Overall dimensions (L×W×H)	550×450×610mm	700×360×470mm	1125×650×1180mm	1280×750×1250mm
Net weight	90kg	300kg	660kg	880kg

Features

Flexible product sizing
Equipped with multiple interchangeable perforated screens for producing cylindrical extrudates ranging from 0.5mm to 3.0mm in diameter.
Low-shear radial extrusion Compared with single-screw extruders, the radial screw design applies less shear force, minimizing friction and heat generation. This enhances plastic deformation while maintaining the stability of heat-sensitive materials during processing.
Thermal adaptability The extruder can be equipped with a cooling or heating jacket to meet the specific requirements of different material types.

For powder processing, we also provide a .
