PP/PS/PE Plastic Sheet Extrusion Line
The PP/PS/PE plastic sheet extrusion machines are engineered to deliver high-quality and precise sheet production for diverse industries. By combining extrusion, calendering, and winding processes, the system converts raw plastic pellets into sheets or roll stock ready for thermoforming. Capable of processing PS, PP, and HIPS polymers, it supports applications such as plastic cups, bowls, trays, blister packs, and stationery packaging. With versatile performance and dependable operation, it provides manufacturers with a reliable solution tailored to meet various production needs.
| Model | |
| Applicable material | PP/PS/PE |
| Sheet layers | 1-5 layers |
| Production capacity | 150-250kg/h (can be customized) |
| Screw diameter | Optional 120/130150mm |
| L/D ratio | 35:1, graded separation |
| Screw speed | 80rpm |
| Die width | 900mm |
| Effective sheet width | 780mm |
| Sheet thickness | 0.3-3.5mm |
| Main motor | 75kW |
| Upper calender | Ø450×900mm |
| Middle calender | Ø450×900mm |
| Lower calender | Ø450×900mm |
| Chiller calender | Ø200×900mm |
| Rewinding method | Independent winding |
| Max. rewinding diameter | 800mm |
| Total power | 180kW |
| Power supply | 380V, 3 phase, 50Hz |
| Machine dimensions (L×W×H) | 17×3×2.6m |
| Machine weight | 12t |
-
Movable rewinder
-
Traction unit
-
Trimming edge
-
Three-roll calendar
-
T-die head
-
Screw & barrel
-
Electrical panel
-
Material loader
-
Gearbox
-
Main motor
- Pre-drying of raw materials
- Heating, conveying, and compressing of pellets by screw and barrel
- Melting and mixing, followed by filtration
- Melt delivered through die head under stable pressure
- Sheet formation and calendering
- Three-roll calendering for pressing, cooling, and shaping
- Edge trimming to the required width
- Sheet conveying and natural cooling
- Double roll winding with constant tension
-
- 1
Adopts advanced horizontal three-roll calender technology, making operation simple and easy to monitor
-
- 2
High efficiency with large-capacity extrusion and low power consumption
-
- 3
Screw design with large L/D ratio ensures superior plasticizing performance
-
- 4
Ergonomically designed for ease of use, comprehensive functions, and reliable operation
-
- Touchscreen control panel
-
- PLC system
-
- Inverter
-
- Contactor
-
- Screw & barrel diameter: Ø110 mm
- Material: high-quality 38CrMoAlA
- Nitriding depth: 0.4-0.6 mm
- Screw hardness: 740 HV
- Barrel cover: stainless steel, prevents excessive heat loss, energy-saving design
- Cooling: air-cooled with independent zone temperature control via fans
- Main motor: 75 kW
- Inverter: high-performance constant torque, stable speed, and precise control
Extruder -
- Die head width: 900 mm
- Maximum sheet width: 780 mm
- Heating: 5 zones, 3 kW/zone
- Material: 40Cr forged steel
T-die mold -
- Structure: horizontal three-roll calender
- Drive system: independent drive control for each roll, adjustable individually or simultaneously
- Motor & drive: reducer servo motor (Delta, Taiwan)
- Bearings: NSK (Japan) spherical ball bearings
- Pressing: turbine worm gear double-pressure system
- Gap adjustment: worm gear structure
- Tablet press movement: electrically driven forward/backward
- Roll material: 45# steel, heat treated, with uniform surface cooling
- Roller precision: diameter jump ≤8 μm
- Surface hardness: HRC 55-58
- Coating hardness: HRC 60-62
- Motors: 3 × 3 kW
- Cooling: three-roller circulating water cooling with internal screw-type rollers for efficiency
Calender (three-roll unit) -
- Cutter type: duplex cutter
- Blade material: high-quality alloy steel
- Knife frame: adjustable lateral width
- The waste edge can connect with online crusher
Waste edge trimming -
- Double rewinder maximum roll diameter: Ø700 mm
- Maximum roll weight: 600 kg/roll
- Drive: specialized reducer and torque motor
- Suitable for small sheet rolls
Roll rewinder -
- Maximum roll diameter: Ø1700 mm
- Maximum roll weight: 2000 kg/roll
- Freestanding design, ideal for in-house factory use
- Allows extended operation without frequent roll changes, reducing labor requirements
Independent mobile winder
