4×2 Dump Truck

Request a Quote

Website: http://heavytrucks-en.com/2-1-1-4-2-dump-truck.html

CONSTRUCTION TRUCKS

This 4×2 dump truck is equipped with a 290 HP engine, 9-speed transmission, and a 13-ton dual reduction rear axle. Designed for efficient short-haul and urban transport tasks, it offers a balance of power and payload for smaller-scale construction and municipal operations.

Engine power 290 HP / 2200 rpm
Gross vehicle weight 19,000 kg
Cargo box volume 8-10 m³
Rear axle type 13-ton dual reduction drive axle

Dimensional Drawing

Specifications

Model	1929K
Driving Type	4×2
Engine	Type: WP10.290E32 Version: EURO II Displacement (I): 9,726 Max. Power (HP/rpm): 290/2200 Max. Torque (N.m/rpm): 1160/1200~1600 Cylinder: 6 in-line
Transmission	9JS150A / 15.53-1 Gears: 9 speed forward Synchromesh or Constant Mesh: Constant Mesh Transfer Box: not available Power Take-Off (P.T.O.): yes
Steering System	8098 Recirculating ball steering gear, hydraulic booster
Clutch	Ø430mm single dry friction disc, diaphragm spring, pushing type
Fuel Tank	400L (iron)
Front Axle	7500kg, non-drive steering
Rear Axle	13000kg, double reduction driving axle, hydraulic shock absorber, differential lock
Suspension	Front 13pcs / Rear 9 8pcs hard parabolic spring
Brakes	Service: dual circuit air brakes Emergency/Parking: spring potential brake Auxiliary: EVB (optional ABS)
Electrical Equipment	Alternator: 70Amp Starter Motor: 5.5kW Batteries: 2×12V – 135AH
Performance Data	Gradeability@GVM: 30% Max. Geared Road Speed: 80km/h Final Drive Ratio: 5.263 (optional 4.769, 5.921)
Tyre	Size and Ply Rating: 12.00R20-18PR Steel Rim
Dumper Cargo Box	Size: 5000×2300×700mm, front lifting system
Dimensions	Wheel Base (WB): 4800mm Overall Length (OL): 7100mm Overall Width (OW): 2550mm Overall Height (OH): 3670mm Front Overhang (FOH): 1515mm Rear Overhang (ROH): 1175mm
Total Vehicle Weight	10000kg

*The above data is subject to the actual product.

Applications

Urban sanitation: With a cargo capacity of 8-9 m³, the 4×2 dump truck is ideal for municipal sanitation work. It handles frequent stops and narrow city streets with ease, and features a sealed cargo box to prevent leakage, ensuring clean and efficient all-weather operations.
Earthmoving and short-haul transport: Capable of efficiently hauling up to 10 tons of sand, gravel, or soil over short distances. Its high-torque engine (≥1100 N•m) tackles muddy construction sites, while the low center of gravity ensures stable dumping on uneven terrain.
Infrastructure and agricultural support: Suitable for transporting up to 10 tons of mixed construction materials or agricultural products. The hydraulic lifting system supports unloading on slopes, and all-terrain tires paired with a reinforced suspension enhance durability on unpaved rural roads.

Related Dump Trucks

What is your production lead time?

Our usual production cycle is 55 to 65 days, depending on specific configurations and order requirements.
