Tempering Oven, Industrial Heat Treat Oven Manufacturer

Tempering Oven, Industrial Heat Treat Oven

Request a Quote

View All: http://heating-melting.com/2-1-3-tempering-oven-industrial-heat-treat-oven.html

Heating and Melting Equipment

We are a leading manufacturer of high-quality industrial heat treat oven for industrial heat treatment applications. These ovens are available in a variety of sizes and heating systems designed to meet unique customer application needs.

Applicable products

Micro-parts (like chains, watches, instruments parts)
Inner and outer bearing rings
Hardware tools
Sewing machines
Motorcycle parts

Parameters

Model		HXZR Series
Model		Heating furnace	Quenching tank	Cleaning machine	Tempering furnace	Heating furnace	Quenching tank	Cleaning machine	Tempering furnace
Rated power (KW)		75	1.5/7.5	1.5	35	90	2.1/30	1.5/15	80
Rated voltage (V)		380	380	380	380	380	380	380	380
Rated temperature (℃)		950	0～60～120	0～80	650	950	0～60～120	0～80	650
Phase		3	3	3	3	3	3	3	3
Frequency (Hz)		50	50	50	50	50	50	50	50
Working area dimensions	Length (mm)	3500	2500	2600	5040	4700	3000	3200	5400
	Width (mm)	300	400	400	500	300	450	400	600
	Height (mm)	50	200	200	130	50	200	210	80
Belt speed (mm/min)		17～180	17～180	17～180	17～180	17～180	17～180	17～180	17～180
Gas consumption (m3/h)		8～10				9～12
Production rate	Quenching (kg/h)	150	150	150	150	200	200	200	200
	Carburizing (kg/h)	80	80	80	80	100	100	100	100
	Carbonitriding (kg/h)	45	45	45	45	55	55	55	55
Furnace mass (kg)		3600	3000	3200	4800	5200	4500	4300	6500
