MHF Cable，Aluminum Mobile Home Feeder Cable
Request a Quote
Mobile home feeder cable consists of four AA-8000 series aluminum alloy conductors: two phase conductors, a white striped neutral conductor and a green equipment grounding conductor. The conductors are insulated with type RHH/RHW-2/USE-2 cross-linked polyethylene (XLPE).
Aluminum MHF cable can be used at max. voltage of 600V and at a max. conductor temperature of 90℃ for direct burial in wet, damp or dry locations.
Applications:
MHF cable is designed for the connection of mobile homes to electric power supply.
Standards:
Our aluminum mobile home feeder cable meets UL 44 and UL 854 and has passed the following tests: FT2 horizontal flame test, 720h sunlight resistance test, aging test on insulation materials, dielectric voltage withstand test, etc.
Specifications:
| Part Number | Insulated Phase Conductors | Insulated Neutral Conductor | Insulated Equipment Grounding Conductor | Complete Cable Diameter(mm) | |||
| Nominal Diameter | Insulation Thickness | Nominal Diameter | Insulation Thickness | Nominal Diameter | Insulation Thickness | ||
| 2X2 1X4 1X6 | 6.81 | 1.52 | 5.41 | 1.52 | 4.29 | 1.52 | 21.2 |
| 2X2 1X2 1X4 | 6.81 | 1.52 | 6.81 | 1.52 | 5.41 | 1.52 | 22.7 |
| 2X2/0 1X1 1X4 | 9.55 | 2.03 | 7.59 | 2.03 | 5.41 | 1.52 | 28.5 |
| 2X2/0 1X2/0 1X1 | 9.55 | 2.03 | 9.55 | 2.03 | 7.59 | 2.03 | 31.7 |
| 2X4/0 1X2/0 1X4 | 12.07 | 2.03 | 9.55 | 2.03 | 5.41 | 1.52 | 32.6 |
| 2X4/0 1X4/0 1X2/0 | 12.07 | 2.03 | 12.07 | 2.03 | 9.55 | 2.03 | 37.3 |
