AS-1800 Steam Shrink Tunnel
1.8m steam tunnel for shrink sleeve labels
- 1.8m steam shrink tunnel
- Heating method: steam
The steam shrink tunnel uses hot steam to securely adhere shrink sleeves to bottles of various shapes and sizes. Equipped with adjustable steam nozzles and scale markers, it ensures flexible operation and convenient adjustments. The durable stainless steel frame is designed for long-term production and meets the stringent requirements of the food packaging industry.
The efficiently designed internal steam circulation system enhances steam flow efficiency, further improving shrink quality. The shrink tunnel employs standardized component assembly, resulting in low maintenance costs and a low failure rate. It is compatible with belt conveyors of various specifications, making it an ideal solution for large-scale shrink packaging of bottled products.
- Voltage: 3P/220V~415V
- Machine Dimensions (L×W×H): 1800×500× 610mm
- Tunnel Dimensions (L×W×H): 1800×150×420mm
- Motor Power: 0.4kW
- Steam Pressure: 0.5 ~ 1 kg.cm2
- Steam Consumption: 100 ~ 200 kg/hr
- Observation Window: 1
- Easy installation and sleek design.
- Steam nozzle can be adjusted as needed.
- Machine body is made of stainless steel, ensuring durability and suitability for most packaging applications.
- This shrink tunnel is available in two models i.e. AS-1800B and AS-1800C, the difference between these two is that AS-1800B includes reinforced glass for easy inspection of the internal tunnel conditions.
- Both AS-1800BD and AS-1800C have two steam storage tanks, one of which is used for installing the preheating tunnel.
- Larger scale on shaft for more convenient and quick adjustments.
- Standardized parts for quick and safe maintenance.
- Specially designed tunnel interior for better steam flow and shrinking quality.
- Neck Tamper Evident Banding This is suitable for sealing the necks of various bottles and cans, preventing product tampering or foreign contaminants before sale, thus preserving the product's originality and quality.
- Full Body Over-The-Cap Sleeve Labeling Labels cover the entire bottle, from the neck down to the bottom. This is commonly used for products such as sauces and condiments.
- Full Body Shrink Sleeve Labeling Labels cover the range from just below the bottle neck to its bottom. This is frequently used for products like juices and coffee.
- Partial Body Shrink Sleeve Labeling This is a common packaging type where labels are positioned in the center of the bottle body. It is frequently used for various bottled and canned products.
- Full Body & Underlap Sleeve Labeling Designed specifically for packaging requirements that involve covering the entire bottle, from the neck down to the bottom. This showcases the product design aesthetics for a more visually appealing appearance.
Our steam shrink tunnel is widely used in the shrink sleeve packaging of beverages, dairy products, pharmaceuticals, personal care products, and food packaging in the packaging industry. It is suitable for bottles or containers of different sizes and shapes, including square, curved, cup-shaped, and unique bottle types.
