Anchor Tensiometer
Request a Quote
TBTML-series pull out test apparatus is suitable for testing the anchorage force of bolt, steel bar, expansion bolt, etc.
Technical Parameters
Model | Cylinder center hole | Cylinder stroke | Test range | Cylinder weight | Anchor size | Pull rod | Conversion head |
10T | 27mm | 60mm | 0-100kN | 5.5kg | Ø6-20 | M18 | M6-20 |
20T | 35mm | 80mm | 0-200kN | 13kg | Ø6-25 | M24 | M6-24 |
30T | 45mm | 80mm | 0-300kN | 15kg | Ø6-32 | M30 | M6-30 |
50T | 60mm | 120mm | 0-500kN | 25kg | Ø6-40 | M39 | M6-36 |
100T | 85mm | 150mm | 0-1000kN | 58kg | Ø25-40 | M45 | M30-39 |
