• Inner tube: Nitrile Butyl rubber compound (Tensile strength ≥12MPa)
• Reinforcement: Single layer of textile cord braiding
• Outer cover: Butyl Chloroprene rubber compound (Tensile strength ≥10MPa)
• Working temperature: -20°C to 80°C
• Safety factor: 3:1
• Color: Available in various colors such as black, red, etc.

Our R6 hydraulic hose is a light weight hydraulic system component that is specially designed for oil suction and discharging of various petroleum products that do not exceed a maximum of 20% aromatic content. The reinforcement of the oil hose effectively prevents any system leakage that could result in downtime.

• The inner tube exhibits excellent oil resistance, ensuring prolonged delivery of hydraulic oil.
• The outer cover boasts high strength and exceptional abrasion resistance, enabling normal operation under various working conditions.

The R6 rubber hose finds widespread applications, particularly in industrial, shipbuilding, petrochemical, and automotive sectors for transmission systems such as hydraulic systems, fuel transfer systems, braking systems, cooling systems, etc. It is also extensively used in construction, agricultural machinery, railways, aviation, and other fields.

Technical Parameters
