YC76 Pneumatic Automatic Hose Cutting Machine
Request a Quote
Application
Yong-Feng YC76 automatic pneumatic hose cutting machine driven by 110V-480V AC is used to cut hose with the inner diameter up to 3 inch. It can be connected with pneumatic pumps to automatically cut hose and thus it largely reduces labor cost. To protect operators and the environment, the hose cutting machine is equipped with a safety shield and a smoke pipe.
| Cutting range | 6-76mm |
| Hose size | 3"4SP /2"6SP |
| Drive | 3kw |
| Standard voltage | Customized |
| Control | Pneumatic automatic |
| Weight | 249 kg |
| Cutting blade | 2 pcs |
| Safety shield | Included |
| Pneumatic input | 6-8 bar |
| Blowing and fume extraction | Available |
| L x W x H | 955*1020*780mm |
